AMP Research Powerstep 77158-01A Installation Manual
  1. Manuals
  2. Brands
  3. AMP Research Manuals
  4. Automobile Accessories
  5. Powerstep 77158-01A
  6. Installation manual

AMP Research Powerstep 77158-01A Installation Manual

Ram 1500 crew cab 2009-2012 ram 2500/3500 crew cab 2010-2012
Hide thumbs

Advertisement

Quick Links

Download this manual
APPLICATION
Ram 500
Ram 2500/3500
Note:The application works only on the Crew Cab model Vehicles.
AMP RESEARCH TECH SUPPORT -888-983-2204 (Press 2) Monday - Friday, 6:00 AM - 5:00 PM PST
Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one of the following patents:
6,64,58; 6,830,257; 6,834,875; 6,938,909; 7,055,839; 7,380,807; 7,398,985; 7,584,975 ©202 AMP Research. All rights reserved.
Printed in USA.
www.amp-research.com
I N S T A L L A T I O N G U I D E
Crew Cab
2009-202
Crew Cab
200-202
/3
AMP Part #
7758-0A
7758-0A
INSTALLATION TIME
3-5 Hours
Professional installation recommended
SKILL LEVEL
 2 3
4= Experienced
TOOLS REQUIRED
q Safety goggles
q Measuring tape
q 0 mm socket
q 3 mm socket
q /2" socket
q Ratchet wrench and extension
q Wire crimpers
q Wire stripper / cutter
q
3 /6" hex key wrench (allen wrench)
q
4mm hex key wrench ( allen wrench )
q
Electrical tape
q
Weather proof caulking (silicone sealer)
q
Silicone spray
WARRANTY
5-Year Limited Warranty
IM7758 rev 02.02.6
