APPLICATION
Chevrolet Silverado1500 / GMC Sierra 1500 - Crew Cab 2007-2013
Chevrolet Silverado 2500/3500
GMC Sierra 2500/3500
(Excludes all 2011-up models with Diesel Engine)
Note:The application works only on the Crew Cab model Vehicles.
AMP RESEARCH TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 7:00 AM - 5:00 PM PST
Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one of the following patents:
6,641,158; 6,830,257; 6,834,875; 6,938,909; 7,055,839; 7,380,807; 7,398,985; 7,584,975 ©2012 AMP Research. All rights reserved.
Printed in USA.
www.amp-research.com
I N S T A L L A T I O N G U I D E
- Crew Cab 2007-2014
1/11
AMP Part #
77126-01A
77126-01A
INSTALLATION TIME
3-5 Hours
Professional installation recommended
SKILL LEVEL
2 3
1
4= Experienced
TOOLS REQUIRED
q Safety goggles
q Measuring tape
q Power Drill
q 10 mm socket
q 13 mm socket
q 1/2" socket
q Ratchet wrench and extension
q Wire crimpers
q Wire stripper / cutter
q
3 /16" hex key wrench (allen wrench)
q
4mm hex key wrench ( allen wrench )
q
Electrical tape
q
Weather proof caulking (silicone sealer)
q
Silicone spray
WARRANTY
5-Year Limited Warranty
IM77126 rev 01.21.20
4
Advertisement
Related Manuals for AMP Research 77126-01A
Summary of Contents for AMP Research 77126-01A
- Page 1 AMP RESEARCH TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 7:00 AM - 5:00 PM PST Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one of the following patents: 6,641,158; 6,830,257; 6,834,875; 6,938,909; 7,055,839; 7,380,807; 7,398,985; 7,584,975 ©2012 AMP Research. All rights reserved.
-
Page 2: Exploded View
A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C INSTALLATION GUIDE Attaching motor to Linkage assembly. EXPLODED VIEW •... - Page 3 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C (A) End cap left (x1) (B) End cap right (x1) (C) T-nut insert (x2) (D) Socket cap screw (x2) (E) End cap wedge right (x1)
- Page 4 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C 5/16-18 Socket Cap M8 U-nut M6 Flange Bolt M5 Hex Bolt M5 Washer Carriage Bolt...
- Page 5 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Insert and position Carriage bolts (15) into slot on rail (4). Insert from either end of rail. Using Flange Nuts (12) provided assemble Brackets 2x (27) &...
- Page 6 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Slide mounting T-nut into position, Center board in Using a 13mm socket Torque linkage bolts 4x (8) rail pocket.
- Page 7 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Using the two 11” cable ties, mount controller to Remove power fuse.
- Page 8 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Pull up the carpet and thread both wires through the REAR DOORS - Carefully remove wire wrap and floor panel (same steps on passenger side EXCEPT...
- Page 9 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Remove plastic trim on door near mirror attachment. Remove all plugs from switchplate Then carefully pry up window/ door lock switch plate.
- Page 10 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C For 2007-2009 Models: For 2010-Current models: Locate the brown plug in doors and using supplied Locate loom that runs across the top of the door Posi-Tap™...
-
Page 11: Final System Check
A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Check that all doors activate the Power Step and the LED Lights work when doors open and close. - Page 12 5-YEAR LIMITED WARRANTY AMP RESEARCH warrants this product to be free from defects in material and workmanship for FIVE (5) YEARS FROM DATE OF PURCHASE, provided there has been normal use and proper maintenance. This warranty applies to the original purchaser only.
