EVAL-M1-CTE620N3 board specifications

Table 2 depicts the important specifications of the evaluation board EVAL-M1-CTE620N3.
Table 2 EVAL-M1-CTE620N3 board specifications
Parameters
Input
Voltage
Input current
Output
Power (3phases)
Current per leg
DC Bus Voltage
Maximum DC bus voltage
Minimum DC bus voltage
Switching Frequency
Inverter switching frequency
f
PWM
Current feedback
Inverter current sensing resistor
RS3,RS4,RS5
Protections
Output current trip level
Temperature trip level
On board power supply
15 V
3.3 V
PCB characteristics
Material
Dimension
System environment
Ambient temperature
For iMOTION™ IC IMC1xx, there are three types of Gatekill Input Source (Refer to section 5.1.3 or control board user manual for
1
detail). Please note that, if select comparator for Gatakill Input Source, the external Gatakill signal will be not used. And the leg
I_Shunt will be compared by the internal comparator with the "Gatekill Comparator Reference" value set in MCEWizard only.
User Manual
Values
165 - 265 V
rms
6.4A
rms
1200 W
6.8A
rms
420 V
120 V
20 kHz (max)
30 mΩ
1 14.7 A
peak
100 °C
15 V ± 2 %, max. 500 mA
3.3 V ± 1 %, max. 300 mA
FR4, 1.6mm thickness, 2
layers.
35 µm copper thickness
121 mm x 120 mm
From 0 to 50°C
7 of 37
Conditions / comments
lower AC input, less motor power output
input 220 V , T =25°C, IM393
AC a
input 220V , f =6 kHz, T
AC PWM
T =80°C(Refer to figure 2 curve)
h
input 220V , f =6 kHz, T
AC PWM
Configured by changing pull up resistor R30.
For controller board Eval-M1-101T
Used for CIPOS™ IPM gate driver and LDO
Supplying the 3.3V to the controller board and
protection circuits
Non-condensing, maximum RH of 95 %
=25°C,
a
=25°C, T =80°C
a h
Revision 1.0
2018-08-23
