EVAL-M1-CTE620N3 main features
2 GND
3 PWMUL
4 GND
5 PWMVH
6 +3.3V
7 PWMVL
8 +3.3V
9 PWMWH
10 I_U
11 PWMWL
12 I_U-
13 GK
14 DCBSense
15 VTH
16 I_V
17 I_V-
18 I_W
19 I_W-
20 VCC
Table 5 provides the details of the motor side connector J2.
Table 5 J2 - Motor side connector
S. No. Pin
1 U
2 V
3 W
Table 6 provides the details of the Fan connector J4.
Table 6 J4 – Fan Connector
S. No. Pin
1 15V
2 GND
User Manual
Ground
3.3 V compatible logic input for low side gate driver-Phase U
4 GND Ground
3.3 V compatible logic input for high side gate driver-Phase V
On board 3.3 V supply
3.3 V compatible logic input for low side gate driver-Phase V
On board 3.3 V supply
3.3 V compatible logic input for high side gate driver-Phase W
Positive Current sense output
3.3 V compatible logic input for low side gate driver-Phase W
Negative current sense output or Ground
Gate kill signal – active low when overcurrent is detected
DC bus positive voltage, scaled in 0-3.3 V range by a voltage divider
Thermistor Output
Positive Current sense output
Negative current sense output or Ground
Positive Current sense output
Negative current sense output or Ground
15 V Power Supply
Details
Connected to motor phase U
Connected to motor phase V
Connected to motor phase W
Details
Connected to 15V
Connected to Ground
