3.6.14 Universal Host-Port Interface (UHPI)
Note:
The UHPI module requires 16 data pins for the host port interface to function. Therefore on the PTP, the
UHPI is not available.
Table 3-19. Universal Host-Port Interface (UHPI) Terminal Functions
SIGNAL NAME
EMA_D[15]/UHPI_HD[15]/LCD_D[15]/GP0[15]
EMA_D[14]/UHPI_HD[14]/LCD_D[14]/GP0[14]
EMA_D[13]/UHPI_HD[13]/LCD_D[13]/GP0[13]
EMA_D[12]/UHPI_HD[12]/LCD_D[12]/GP0[12]
EMA_D[11]/UHPI_HD[11]/LCD_D[11]/GP0[11]
EMA_D[10]/UHPI_HD[10]/LCD_D[10]/GP0[10]
EMA_D[9]/UHPI_HD[9]/LCD_D[9]/GP0[9]
EMA_D[8]/UHPI_HD[8]/LCD_D[8]/GP0[8]
EMA_D[7]/MMCSD_DAT[7]/UHPI_HD[7]/GP0[7]/
BOOT[13]
EMA_D[6]/MMCSD_DAT[6]/UHPI_HD[6]/GP0[6]
EMA_D[5]/MMCSD_DAT[5]/UHPI_HD[5]/GP0[5]
EMA_D[4]/MMCSD_DAT[4]/UHPI_HD[4]/GP0[4]
EMA_D[3]/MMCSD_DAT[3]/UHPI_HD[3]/GP0[3]
EMA_D[2]/MMCSD_DAT[2]/UHPI_HD[2]/GP0[2]
EMA_D[1]/MMCSD_DAT[1]/UHPI_HD[1]/GP0[1]
EMA_D[0]/MMCSD_DAT[0]/UHPI_HD[0]/GP0[0]/
BOOT[12]
EMA_A[2]/MMCSD_CMD/UHPI_HCNTL1/GP1[2]
EMA_A[1]/MMCSD_CLK/UHPI_HCNTL0/GP1[1]
EMA_BA[1]/LCD_D[5]/UHPI_HHWIL/GP1[13]
EMA_WE/UHPI_HRW /AXR0[12]/GP2[3]/BOOT[14]
EMA_CS[2]/ UHPI_HCS /GP2[5]/BOOT[15]
EMA_WE_DQM[1]/ UHPI_HDS2 /AXR0[14]/GP2[8]
EMA_OE/ UHPI_HDS1 /AXR0[13]/GP2[7]
EMA_WE_DQM[0]/ UHPI_HINT /AXR0[15]/GP2[9]
EMA_WAIT[0]/ UHPI_HRDY /GP2[10]
EMA_CS[0]/ UHPI_HAS /GP2[4]
(1) I = Input, O = Output, I/O = Bidirectional, Z = High impedance, PWR = Supply voltage, GND = Ground, A = Analog signal.
Note: The pin type shown refers to the input, output or high-impedance state of the pin function when configured as the the signal name
highlighted in bold. All multiplexed signals may enter a high-impedance state when the configured function is input-only or the configured
function supports high-Z operation. All GPIO signals can be used as input or output. For multiplexed pins where functions have different
types (ie., input versus output), the table reflects the pin function direction for that particular peripheral.
(2) IPD = Internal Pulldown resistor, IPU = Internal Pullup resistor
Copyright © 2008–2014, Texas Instruments Incorporated
PIN NO
PTP ZKB
- M16
- N14
- N16
- P14
- P16
- R14
- T14
- N12
- M15
- N13
- N15
- P13
- P15
- R13
- R15
- T13
- P9
- R9
- P8
- M13
- P7
- P12
- R7
- M14
- N6
- T8
Submit Documentation Feedback
Product Folder Links: TMS320C6745 TMS320C6747
TMS320C6745, TMS320C6747
SPRS377F – SEPTEMBER 2008 – REVISED JUNE 2014
(
TYPE
(2)
PULL MUXED
1)
I/O IPD
I/O IPD
I/O IPD
I/O IPD
EMIFA, LCD, GPIO
I/O IPD
I/O IPD
I/O IPD
I/O IPD
EMIFA, MMC/SD,
I/O IPU
GPIO, BOOT
I/O IPU
I/O IPU
I/O IPU
EMIFA, MMC/SD,
GPIO
I/O IPU
I/O IPU
I/O IPU
EMIFA, MMC/SD,
I/O IPU
GPIO, BOOT
I/O IPU EMIFA,
MMCSD_CMD,
I/O IPU
GPIO
I/O IPU EMIFA, LCD, GPIO
EMIFA, McASP,
I/O IPU
GPIO, BOOT
EMIFA, GPIO,
I/O IPU
BOOT
I/O IPU
EMIFA, McASP0,
I/O IPU
GPIO
I/O IPU
I/O IPU
EMIFA, GPIO
I/O IPU
DESCRIPTION
UHPI data bus
UHPI access control
UHPI half-word
identification control
UHPI read/write
UHPI chip select
UHPI data strobe
UHPI host interrupt
UHPI ready
UHPI address
strobe
Device Overview 41
