1.2.2
Controller Boards
The TX3-TOUCH-S15B-WR and TX3-TOUCH-S15S-WR contain the
following components and controller boards as shown in Figure 4:
•
•
•
•
•
•
•
To access the panel, unlock the door and swing it open.
4
TX3-TOUCH-S15B-WR and TX3-TOUCH-S15S-WR Installation
LT-6651
Copyright 2019
TX3-TOUCH-S15B-WR and TX3-TOUCH-S15S-WR Installation
Power Switch
USB Port
Lobby Controller
PC Sub Compact Board with Ethernet Port
Power Supply and Audio Mixer Board
Fan
Speakers
Power
Terminals
+
-
Ground
Screw
16 Gauge
Wire to
Ground
Figure 4. Controller Board Panel
Telephone Line
PC Sub Compact
Board
Ethernet
Lobby
Controller
Power
Supply and
Audio Mixer
Board
Speaker
Fan
Tamper switch
On/Off
USB Port for
Keyboard
Power Switch
Speaker
Version 1
