Power cable to
TS10B on MD-1236
TX3-TOUCH-S15B-WR and TX3-TOUCH-S15S-WR Installation
Version 1
LT-6651
Copyright 2019
TX3-TOUCH-S15B-WR and TX3-TOUCH-S15S-WR Installation
Figure 11. Display connections
WX-084 to
ground post
on door
WX-070
WX-019
Figure 12. Ground wires
VGA cable to CN30
on PC board
USB to PC board
WX-070
11
