External Power Supply
MD-990 156 W, 24 V single output switching power supply
Input voltage: 88 VAC to 132 VAC
Door Strikes
Select the appropriate door strike as required by your system applications. We
recommend using the following Mircom door strikes below and its compatible
power transformer.
• Mircom Model M-10. DC (silent) or AC (buzzing) Door Strike. (Use PS-3B
transformer)
Note: The door strike must have its own separate power transformer. Do not tap
or use the system power transformers. When using a different door strike and
door strike transformer, the maximum strike load that may be switched through
the control unit is 28 VAC or 1 Amp DC.
The maximum supply for the AC or DC Input Door Strike must not exceed:
• 28 VAC / 1 A max.
• 30 VDC / 1 A max.
Outputs 2-4
Relays with these contact ratings:
• 125 VAC / 2 A
• 30 VDC / 1 A
Telephone Lines
Use only Loop Start telephones (not ground start), check with your local tele-
phone company.
Operating Temperature
-20°C (-4°F) to 50°C (122°F)
