Replacement Card Reader Window and Camera
Window for TX3-TOUCH-S15B-WR and
TX3-TOUCH-S15S-WR
Figure 1
Card Reader Window Replacement
A. Disconnect the Power
B. Remove the Card Reader Assembly
Remove the card reader, the metal bracket, and the plastic plate.
Figure 2
C. Replace the Card Reader Window
D. Replace the Card Reader Assembly
Replace the plastic plate, the metal bracket, and the card reader as shown in Figure 2.
You are done! If you need more help, call us at 1-888-660-4655.
LT-6649 Rev 0
2.59"
2.2"
Card reader window
Card reader window and camera window dimensions
Card reader plastic plate
Card reader window
Parts of the card reader assembly
1.87"
Camera window
Card reader metal bracket
4x nuts
4.6"
Card reader
2 x screws
