1.5.1 Maximum Power Supply Wire Distances
The distance from the Touch Screen to the power supply is a function of the wire
gauge and the resistance generated by the cable by the power draw.
Do not exceed the maximum distances from the Touch Screen to the power
supply as indicated in Table 1.
1.6

Turning the Touch Screen On and Off

Note:
To turn on the Touch Screen
1.
To shut down the Touch Screen
1.
2.
3.
4.
8 TX3-TOUCH-S15B-WR and TX3-TOUCH-S15S-WR Installation
LT-6651 Copyright 2019
TX3-TOUCH-S15B-WR and TX3-TOUCH-S15S-WR Installation
Table 1: Maximum Power Supply Wire Distances
Gauge
16
14
12
10
Never turn off power when the system is operational.
Press the power switch (see Figure 4).
On the Touch Screen display, enter 9999.
Enter your administrator password, and then press OK.
Select File > Shut down > Shut down.
Do not disconnect the power until the full shut down process has been
completed.
Distance
125 ft (38.1 m)
200 ft (60.96 m)
320 ft (97.536 m)
500 ft (152.4 m)
