Event Lighting F100WWMZ User Manual page 4

Menu
Level 1 Level 2
DMX DMX address
CHAN CH01
CH02
CH03
Manual DIM
D_F
STO
CURVE Linear
Log
S
Reset YES/NO
TEMP C.000
FAN Max
Auto
Silent
FADE ON/OFF
VERSION A109.01
Press Up and Down to select the desired operation, press Enter to select.
Set DMX Address
Select "DMX" then press Enter.
Use Up and Down to set the desired DMX address from 1 to 512.
Press Enter to confirm and save.
Set DMX Channel Mode
Select "Chan" then press Enter.
Use Up and Down to set the desired DMX channel mode.
Press Enter to confirm and save.
Refer to the DMX Chart below for more information on each mode.
Set Dimmer Curve
Select "Curve" then press Enter.
Use Up and Down to set the desired dimmer curve.
Press Enter to confirm and save.
Set Manual Control
Set the Dimmer, Dimmer Fine and Strobe values through the control panel.
•
Strobe speed 0 is always on, 1-100, strobe slow to fast.
Factory Reset
Select reset and press Enter twice to reset the device to factory default settings.
www.event-lighting.com.au
Value Information
1-512 Set DMX address
Use 1 channel mode
Use 2 channel mode
Use 3 channel mode
0-255 Manual control of Dimmer
0-255 Manual control of Dimmer-Fine
0-255 Manual control of Strobe
Linear dimming curve
Logarithmic dimming curve
S dimming curve
Reset to factory default
Current fixture temperature
Fastest fan speed
Variable fan speed, based on thermal sensor
Theatre mode, meets the Nr25 standard
Enable/disable fade time on dimming
Software version
4
