Crestron CLW-DIM1/4RF, -DIMS1/4RF, -SLVD1RF
Operations Guide - DOC. 6396
CLW-DIM1/4RF, CLW-DIMS1/4RF, & CLW-SLVD1RF Specifications
SPECIFICATION
Operating Ranges¹
Typical Distance
Indoors (without repeater)
Typical Distance Outdoors
Default MNET ID
Switch Type
Load Type
2-Series Control System Update
2,3
File
4
Load Ratings
Incandescent/Tungsten-
Halogen
Magnetic Low Voltage
Operating Temperature and
Humidity
Dimensions and Weight
1. The range is dependent on its placement and the building in which it is used. The construction of the
building, obstructions, and RF interference from other devices are factors determining the effective
range of the unit.
2. The latest software versions can be obtained from the Crestron website. Refer to the NOTE
following these footnotes.
3. Crestron 2-Series control systems include the AV2 and PRO2. Consult the latest Crestron Product
Catalog for a complete list of 2-Series control systems.
4. Refer to Derating Charts for Multigang Installations in the latest version of the infiNET Dimmers
Installation Guide (Doc. 6292) which is available from the Crestron website.
5. VA ratings are for input power to the transformer. If you do not know the input power requirement
of the transformer, use the bulb's wattage rating to determine proper rating.
NOTE: Crestron software and any files on the website are for Authorized Crestron
dealers and Crestron Authorized Independent Programmers (CAIP) only. New users
may be required to register to obtain access to certain areas of the site (including the
FTP site).
infiNET Dimmers: Crestron CLW-DIM1/4RF, -DIMS1/4RF, -SLVD1RF • 3
150 ft
250 ft, subject to site-specific conditions
-DIM1RF/-DIM4RF: 01/01
-DIMS1RF/-DIMS4RF: 01/01
Dimmer
Incandescent, Tungsten-Halogen, Magnetic
Low Voltage
Version 3.154 or later
-DIM1RF/-DIM4RF: 1000W
-DIMS1RF/-DIMS4RF: 1000W
-SLVD1RF: N/A
5
-DIM1RF/-DIM4RF: 1000VA/750W
-DIMS1RF/-DIMS4RF: 1000VA/750W
-SLVD1RF: N/A
32°F to 104°F (0°C to 40°C)
10 to 90% Relative Humidity
(Non-Condensing)
-DIM1RF/-DIM4RF and
-DIMS1RF/-DIMS4RF:
Height: 4.13 in (10.48 cm)
Width: 2.38 in (6.03 cm)
Depth: 1.88 in (4.77 cm)
Weight: 4.9 oz (0.67 kg)
-SLVD1RF:
Height: 4.13 in (10.48 cm)
Width: 1.75 in (4.45 cm)
Depth: 1.88 in (4.77 cm)
Weight: 3.6 oz (0.50 kg)
infiNET™ Dimmers
DETAILS
