infiNET Dimmer Troubleshooting (continued)
TROUBLE POSSIBLE CAUSE(S)
Dimmer If the LED flashes OFF for
presses are ¼ second two times, then
not reported returns to low, the MNET ID
to control of device is not set to match
system. the MNET ID of the SIMPL
Windows program.
If the LED flashes OFF for
¼ second four times, then
returns to low every eight
seconds, the infiNET device
is not transmitting data to
the C2N-MNETGW.
Dimmer is attached to load
and the signal
Enable_Local_Btn_Outputs
is low.
Dimmer Dimmer is detached from
does not the load.
operate as
described in
the manual.
Presets will Mode selection switch is in
not store. the incorrect position.
Trying to store Preset 1 or
Preset 2 when the load is at
0% (Off)
Cannot Mode selection switch is in
recall preset the incorrect position.
light settings.
Slave device -SLVD1RF is detached from
does not the load.
emulate the
RUN mode
of the
-DIMS1RF
(even when
connected to
–DIMS4RF).

Bootloader

In rare cases, it may be necessary to bypass the dimmer's standard firmware and
enter into the "bootloader". This might be necessary if the unit was loaded with a
faulty version of firmware that might prevent future firmware upgrades.
infiNET Dimmers: Crestron CLW-DIM1/4RF, -DIMS1/4RF, -SLVD1RF • 37
infiNET™ Dimmers
CORRECTIVE ACTION
Using Crestron Toolbox, poll
the network. Verify that the
MNET ID for the infiNET
device is set to match the
MNET ID specified in the
SIMPL Windows program.
Open Crestron Toolbox and
select the Network Device
tree. Expand the network
device tree until the gateway
to be managed is selected.
Right-click the Net ID of the
selected gateway to open the
sub-menu and select
Functions|MNET
Gateway.... If devices are not
listed, add devices by putting
the C2N-MNETGW and
infiNET device in Acquire
mode.
In the dimmer symbol of the
SIMPL Windows program, set
the signal
Enable_Local_Btn_Outputs
high.
In the dimmer symbol of the
SIMPL Windows program, set
the signal Detach_Load low.
Set the mode selection switch
to the "SET" position to store
presets.
Set load to higher level.
Set the mode selection switch
to the "RUN" position to recall
presets.
Set the signal
Detach_Load_From_Slave
low.
