Crestron CLW-DIM1/4RF, -DIMS1/4RF, -SLVD1RF
infiNET™ Dimmers:
CLW-DIM1/4RF, -DIMS1/4RF,
-SLVD1RF

Introduction

Operations Guide - DOC. 6396

Features and Functions

The CLW-DIM1RF (-DIM1RF) one-button dimmer and CLW-DIM4RF (-DIM4RF)
four-button dimmer are stand-alone wall box dimmers that can also act as wireless
infiNET™ devices that report to a Crestron
infiNET wireless gateway.
infiNET Dimmers Functional Summary
•
Two-way infiNET dimmers
⇒
2.4 GHz infiNET mesh network technology
⇒
Range up to 150 feet indoors, or 250 ft outdoors (subject to site-
specific conditions)
⇒
Range may be increased with the use of additional infiNET devices
or C2N-MNETRPT repeaters
⇒
"Wi-Fi" friendly operating frequency to avoid interference
•
One-button and four-button configurations available in white, black,
and almond
•
Can be ordered with custom-engraved buttons
•
Can operate as a local load control or infiNET keypad.
The -DIM1RF and -DIM4RF have three preset lighting levels that can be adjusted by
the user. The default preset values are 70% for Preset 1, 100% for Preset 2, and 0%
for Preset 3. Refer to "Operation" on page 9 for more information on using the
dimmer.
These infiNET dimmers are a part of Crestron's line of lighting products using
infiNET mesh network technology. infiNET technology is "Wi-Fi" friendly and
provides fault tolerance and increased effective signal strength as network devices
are added.
As an infiNET device, these dimmers communicate with a Crestron control system
via a C2N-MNETGW infiNET Gateway. Up to 30 infiNET devices (including
infiNET Dimmers: Crestron CLW-DIM1/4RF, -DIMS1/4RF, -SLVD1RF • 1
infiNET™ Dimmers
®
control processor via a Crestron
