Operation

Device overview
Device description
A – 34-pin ERF8 MPC5xxx/SPC5 target pinout:
Signal Signal
Direction Description
I AGBT TX0_P
I AGBT TX0_N
Ground
I AGBT TX1_P*
AGBT TX1_N*
Ground
AGBT TX2_P*
AGBT TX2_N*
Ground
AGBT TX3_P*
AGBT TX3_N*
Ground
Not Connected
Not Connected
Ground
Not Connected
Not Connected
Blue colored signals are Aurora trace signals.
The JCOMP is an optional pin. Some microcontrollers don't have this pin. Internally, this is
actually the JTAG TRST which resets the JTAG TAP state machine. Because the JTAG TAP
state machine can be reset also by the TMS and the TCK, this pin is optional also for the
debugger. If the microcontroller has the JCOMP pin but it is not connected to the target debug
Signal Pin
TX0+ 1
TX0- 3
GND 5
TX1+ 7
TX1- 9
GND 11
TX2+ 13
TX2- 15
GND 17
TX3+ 19
TX3- 21
GND 23
NC 25
NC 27
GND 29
NC 31
NC 33
34-pin ERF8 MPC5x/SPC5x target pinout
Pin Signal
2 Vref
4 TCK
6 TMS
8 TDI
10 TDO
12 nJCOMP
14 NC
16 EVTI0
18 EVTO0
20 nPORST
22 nRESET
24 GND
26 AGBT CLK_P
28 AGBT CLK_N
30 GND
32 NC
34 NC
Signal Signal
Description Direction
Reference
I
Voltage
JTAG O
JTAG O
JTAG O
JTAG I
JTAG TRST
O
(optional)
Not Connected
Nexus Event
O (not used)
Input
Nexus Event
I
Output
Power On
O
Reset
Reset IO
Ground
AGBT Clock O
AGBT Clock O
Ground
Not Connected
Not Connected
