Operation
Device overview
Device description
A – RH850 Aurora target pinout:
Signal
Signal
Direction
Description
I
AGBT TX0_P
I
AGBT TX0_N
Ground
I
AGBT TX1_P
I
AGBT TX1_N
Ground
Ground
Ground
Ground
Blue colored signals are Aurora trace signals.
Signal Direction is described from the BlueBox perspective.
Signal direction definition:
O - Output from the Active Probe to the target microcontroller
I - Input to the Active Probe from the target microcontroller
Signal
Pin
TX0_P
1
TX0_N
3
GND
5
TX1_P
7
TX1_N
9
GND
11
Reserved
13
Reserved
15
GND
17
Reserved
19
Reserved
21
GND
23
Reserved
25
Reserved
27
GND
29
Reserved
31
Reserved
33
34-pin ERF8 RH850 target pinout
Pin
Signal
2
Vref
4
LPDCLK
6
Reserved
8
LPDI
10
LPDO
12
nTRST
14
FLMD0
16
nEVTI
18
nEVTO
20
FLMD1
22
RESETn
24
GND
26
CLK_P
28
CLK_N
30
GND
32
LPDCLKOUT
34
Reserved
Signal
Signal
Description
Direction
Reference
I
Voltage
JTAG
O
JTAG
O
JTAG
I
JTAG
O
Flash Mode
O
Nexus Event
O
Input
Nexus Event
I
Output
Flash Mode
Reset
IO
Ground
AGBT Clock
O
AGBT Clock
O
Ground
LPD
I
