4.15
Fissaggio al suolo delle colonne
Con riferimento alla Fig.21:
- Posizionare la pedana a circa 1' (30 cm) da terra.
- Montare i pattini di guida (1): tali pattini devono aderire ai bordi delle colonne e pertanto può essere necessario un aggiustaggio
degli stessi.
NOTA: I pattini di guida (1) sono presenti solo nelle traverse monolitiche, come evidenziato in figura. I pattini non sono presenti
sulle semitraverse.
- Premere il pulsante di salita (4) ed effettuare una corsa completa: durante tale corsa è bene controllare (eventualmente
fermandosi ogni 8" - 1' (20-30 cm) che lo scorrimento sulle aste asolate avvenga regolarmente e senza anomali sfregamenti:
se si verificano malfunzionamenti è opportuno rivedere la messa a piombo delle colonne.
- Liberare il dispositivo paracadute e la camma controllo funi togliendo le fascette (2-3) ed effettuare una corsa completa di salita
e discesa; con piattaforma a terra procedere quindi alla foratura del terreno (fori Ø 23/32" e profondità 2 3/8") (fori Ø 18 mm
e profondità 60 mm) centrandosi nei fori delle basi delle colonne
- Inserire poi i tasselli in dotazione e bloccare a fondo.
4.16
Registrazione microinterruttori di sicurezza sulle funi
Sollevare le pedane a circa 5' (m. 1,5) da terra; premere il pulsante di stazionamento e fare scendere le pedane in appoggio nelle
asole delle aste asolate.
Premendo il pulsante di discesa la elettrovalvola EV3 non si deve eccitare. Eventualmente riposizionare e regolare i microinterruttori
FC1÷FC4 in modo che questo accada.
4.15
Anchoring the posts
Please refer to Fig.21:
- Place platform about 1' (30 cm) above ground.
- Install the slide guides (1). Slide guides must adhere to post contour and it may be necessary to machine them.
NOTE: Sliding guides (1) are present only on monobloc cross members, as shown in the figure. They are not fitted on semi-cross
members.
- Press the up button (4) and run a full stroke. While platform is moving, check that it slides smoothly along the racks and that no
abnormal friction occurs at any position. You might want to stop the platform every 8" - 1' (20-30 cm) in order to check more
accurately. In the event of malfunction, check that posts are perfectly vertical.
- Remove clips (2-3) to release the safety lock system and the cable control cam. Raise the lift fully and then lower it. With the platform
lowered to the ground, drill 23/32" diam. holes 2 3/8" deep (18 mm diam. holes 60 mm deep) into the flooring. Holes must be
centred to the holes in the post feet.
- Insert the supplied expansion bolts and tighten securely in place.
4.16
How to adjust the safety microswitches on cables
Lift the platforms about 5' (1.5 m) away from ground; press the parking button and lower platforms against the rod slots.
EV3 solenoid valve should not be activated when downstroke button is being pressed. Reposition and adjust the microswitches
FC1÷FC4 if necessary.
ESEGUIRE SEMPRE LA SEGUENTE REGISTRAZIONE:
ALWAYS ACT AS FOLLOWS:
