Summary of Contents for Ravaglioli RAV232 NL
- Page 4 5500...
- Page 5 RAVAGLIOLI S.P.A. AN UFORDERN UND U ERSET EN. VOIR FIGURE. SI CES PICTOGRAMMES SONT ENDOMMAGES IL EST NECESSAIRE DE LES DEMANDER A RAVAGLIOLI S.p.A PUIS DE LES REMPLACER. VER FIGURA EN EL CASO DE UE ESTOS PICTOGRAMAS SE ESTROPEEN ES NECESARIO...
- Page 6 3.1 Lift handling and pre-installation 3.1 Déplacement et pré-installation The supply consists of two cases including the following: La fourniture comprend deux caisses comprenant à l’intérieur: RAV232 NL (VAR23...
- Page 7 - After unpacking, check the lift for possible damages and make sure that all accessories supplied on standard are present. - f the lift is in vertical position, raise it and place it on the ground. f, on the contrary, the lift is in horizontal position, follow the sequence shown on the illustrations in order to place the lift in a vertical position.
- Page 8 - Screw the lifting eyebolt and lift. Visser le piton de levage et lever. Note: the lifting means should reach a height of at least 3000 N.B.: Le moyen de levage doit pouvoir atteindre une hauteur minimum de 3000 mm - Secure the control panel.
- Page 9 - Fit the bracket 1 and the pin 3 to fasten the alignment cable end. - Secure the adjuster into the bracket 1 and insert alignment cable; then fit the other end into the two pulleys 2 and then insert the cable in pin 3. Stretch by hand and secure with clamp 4.
- Page 10 - Screw the lifting eyebolt, position the cable on the forks and lift the post. Note: the lifting means should reach a height of at least 3000 - Visser le piton de levage, positionner le c ble sur les fourches et lever la colonne.
- Page 11 Refer to instructions under step for the installation of the alignment cable. -Carry out all preliminary checks as specified under the relevant paragraph before closing the guard. - Pour le montage du c ble de réalignement, voir les instructions du point - Avant de fermer le carter, effectuer les contr les décrits au paragraphe contrôles préliminaires.
- Page 14 @ @ @ @ @ @ @ @ @ @ @ @...
- Page 19 Per i sollevatori a e colonne ruotare l’interruttore gene- rale A su entrambi i quadri elettrici delle colonne principali. In case of - or -post lifts, turn main switch A on both electric panels in both main posts. ei den -S ulenhebeb hnen den auptschalter A an beiden Schalttafeln der aupts ulen...
- Page 30 ÂÃ Ä Å Æ Ç È Å É ÄÉ Ä Â Ã Ä Å Æ Ç Ç Ã Ç Ä Ç Ä È Å É Ã Ä Â È Ç Ã Ä Æ È ...
- Page 31 ÂÃÄ ÅÆÇÈÅÉ Ä Ä Ç Æ ÈÆÄ Ä ÃÆ ÇÆ ÈÄÄÄ !Ä "Ä#$Ä!Ä %Ä ÉÆÅÆ ÈÄ&ÂÄÂÅÈÄ DC-IN Ry-OUT ÉÄ ÉÆÇÇ Æ ÈÄÈÈ'ÂÆÅÈÄÉÆ((ÂÈÄ ÉÆÆÅÅÈÄ COM0 COM1 %ÃÄ ÈÈ)ÄÉÆÅ ÆÆÄÈ0ÈÅ'ÄÃÂÄ % !Ä ÈÈ)Ä&ÂÄÈÇ È 1ÈÅ'Ä %Ä ÈÈ)ÄÉÆÇ Å&ÆÄ&ÂÉÈÄ %#Ä ÈÈ)ÄÉÆÇ Å&ÆÄÂÄ ( &Ä...
- Page 34 RAV232 NL (VAR230/C4) RAV234 NL (VAR230/C6) RAV236 NL (VAR230/C8) SCHEMA EL.052505680 Fare una connessione con del giallo/verde da 1.5mmq fra il fondo cassetta e una vite di fissaggio del CNF0 capicorda CNF0 cassa CNF0 rondella dentellata NB: POTENZIOMETRO RUOTATO TUTTO A SINISTRA...
- Page 35 BIANCA ROSSA l=290mm SEQUENZA EMERGENZA FASI BLOCCO MONTARE ALL'INTERNO SELEZIONE COPPIE l=180mm 21NC K1 K2 K3 K4 22NC l=180mm 20 19 14 13 CNF8 CNF6 CNF7 FISSAGGIO SUPPORTO COMPONENTI RAV232 NL (VAR230/C4) - RAV234 NL (VAR230/C6) - RAV236 NL (VAR230/C8)
- Page 36 MORS.MICRO 13 MORS.MICRO 13 MORS.MICRO 14 MORS.MICRO 14 MORS.MICRO 21 MORS.MICRO 21 MORS.MICRO 22 MORS.MICRO 22 CAVO MICRO FISSAGGIO SUPPORTO COMPONENTI FCSP PG 21 VAR230/C (CONSOLLE) SCHEMA EL. 052305680 RAV232 NL (VAR230/C4) - RAV234 NL (VAR230/C6) - RAV236 NL (VAR230/C8)
- Page 37 Denominazione tavola - Table definition Valida per i modelli - Apply to models N°tavola Indice di modifica Change index RAV232 NL (VAR230/C4) Table no. RAV234 NL (VAR230/C6) RAV236 NL (VAR230/C8) 5500 RAV232 NL (VAR230/C4) - RAV234 NL (VAR230/C6) - RAV236 NL (VAR230/C8)
- Page 38 Denominazione tavola - Table definition alida per i modelli - pply to models Indice di modifica °tavola Table no. hange index 10A/...
- Page 39 40044 - PONTECCHIO MARCONI/ITALIA É TEL. 051-6781511 - TELEX 510697 RAV I P.O.B. 1690 - 40100 BOLOGNA/ITALIA FAX + 39 (0517 846349) CAPACITY KG. MODEL RAV232 NL (VAR230/C4) SERIAL N YEAR CAPACITY KG. MODEL RAV234 NL (VAR230/C6) CAPACITY KG. MODEL...
- Page 40 Pagina bianca per esigenze di impaginazione This page intentionally blank Freie Seite für Layout Page blanche pour exigences de mise en page Página en blanco por exigencias de compaginación RAV232 NL (VAR230/C4) - RAV234 NL (VAR230/C6) - RAV236 NL (VAR230/C8)
