Evaluation And Test

Setting up the SPI Controller Software

After the ADC data capture board setup is complete, set up the SPI controller software using the
following procedure:
1. Open the SPI controller software by going to the Start menu or by double-clicking the
SPIController software desktop icon. If prompted for a configuration file, select the appropriate
one. If not, check the title bar of the window to determine which configuration is loaded. If
necessary, choose Cfg Open from the File menu and select the appropriate file based on your
part type. Note that the CHIP ID(1) box should be filled to indicate whether the correct SPI
controller configuration file is loaded (see Figure 7).
Figure 6. VisualAnalog, Main Window Expanded Display
