Figure 2. Default Jumper Connections for

Evaluation Board Circuitry

This section explains the default and optional ADC settings or modes allowed on the

and the

AD9637-80EBZ

Power

Connect the switching power supply that is supplied in the evaluation kit between a rated 100V ac to

240V ac, 47Hz to 63Hz wall outlet and P101.

The eight channel inputs on the evaluation board are set up for a double balun-coupled analog input

boards.

Rev 13 Nov 2013 00:23 | Page 6

AD9257-65EBZ/AD9637-80EBZ

Board

AD9257-65EBZ
