CR801 before entering the ADC clock inputs. The AD9653,
with an internal 8:1 clock divider to facilitate usage with higher frequency clocks. When using the
internal divider and a higher input clock frequency, remove CR801 to preserve the slew rate of the
clock signal.
The AD9653-125EBZ,
the transformer-coupled input network from the crystal oscillator, Y801. This oscillator is a low phase
noise oscillator from Valpey Fisher (VFAC3-BHL-125MHz). If a different clock source is desired, remove
C810 (optional) and Jumper J803 to disable the oscillator from running and connect the external clock
source to the SMA connector, J802 (labeled CLK+).
PDWN
To enable the power-down feature, add a shorting jumper across J204 at Pin 1 and Pin 2 to connect
the PDWN pin to DRVDD.

Modes of Operation

Standalone (PIN) Mode

The AD9653/AD9253/AD9633
change the default modes of operation via the SPI. For applications that do not require SPI mode
operation, the CSB pin is tied to AVDD, and the SDIO/OLM pin controls the output lane mode. Table 2
and Table 3 specify the settings for pin mode operation.
Table 2. Output Lane Mode (OLM) Pin Settings
OLM Pin Voltage Output Mode
AVDD (Default) Two-lane. 1× frame, 16-bit serial output
GND One-lane. 1× frame, 16-bit serial output
Table 3. Digital Test Pattern (DTP) Pin Settings
Seected DTP Output Mode Resulting D0±x and D1±x
Normal Operation 10 kΩ to AGND Normal operation
DTP AVDD
Additional information on the lane modes is provided in the AD9653,
AD9253-125EBZ and
ADCs can operate in pin mode if there is no need to program and
1000 0000 0000 0000
