Once the sensor is successfully activated and decoded, the tool will sound
a beep and the screen will display the sensor data with a tick
Notes:
1. The tool will do TPMS test in a sequence of FL (Front Left), FR (Front Right),
RR (Rear Right), LR (Rear Left) and SPARE, if the vehicle has the option for the
spare. Or, you can use the
wheel for testing.
2. If the sensor fails to be triggered, the
position.
3. If the sensor data is abnormal, it will be displayed in red.
3. Repeat Step 2 for other vehicle sensors. After all sensors are successfully
activated, the following screen will appear:
30
.
Figure 5-7
/ / / button to move to the desired
icon will appear next to the wheel
Figure 5-8
www.x431.com +86 755 8455 7891
*Id: indicates the sensor ID.
*P: indicates the tire pressure.
*T: indicates the tire temperature.
Vol: indicates the battery power level.
Note: The sensor ID format, the measurement units of the tire pressure and
temperature can be set to your preference in the

5.2 Program Sensor

This function allows users to program the sensor data to the LAUNCH-sensor
and replace faulty sensor with low battery life or one that is not functioning.
The following options are available for programming LAUNCH-sensor: Auto
Create, Manual Create, Copy ID by Activation and Create Multi-sensor (1-8).
Select PrograM SenSor and press the oK button to enter the following
screen.
Figure 5-9

5.2.1 auto create

This function is designed to program the LAUNCH-sensor by applying random
IDs created according to the test vehicle when it is unable to obtain the original
sensor ID.
Select the wheel which needs to be programmed on the tool, place a
LAUNCH-sensor close to the TPMS antenna of the tool, and select CreaTe
SenSor to create a new random sensor ID.
www.x431.com +86 755 8455 7891
LAUNCH
module.
