ClearCube R1200 User Manual page 48

Table 5 R4300 Remote Management Module Features
Ethernet LEDs
Ethernet LEDs
LINK ACTIVITY
Color
Label
Code
CONTROL IN Green
CONTROL OUT Green
MANAGEMENT —
MODE Blue
FAN MAX —
RST —
DFLT —
RMM MODE —
DHCP —
44 • Chassis and Blade Installation
RMM Reset
Default Switch
Control Chain
Connections
Ethernet
Connection
Connectors
RJ45 connection that receives control and management signals from the previous chassis
in the Control Chain via RS-485. As many as 14 chassis can be connected per Control
Chain.
RJ45 connection that passes control and management signals to the next chassis in the
Control Chain via RS-485.
RJ45 connection that passes control and management signals from the chassis to the
Sentral console via Ethernet. Has two LEDs in socket to indicate Ethernet link speed and
activity. Connection is self-adapting and does not require a crossover cable.
Pushbutton switch that toggles through the blue Mode Selected LEDs on the Connect and
Network Modules. Press this switch to display status for the connections whose blue LED is
lit.
Pushbutton switch that defeats the temperature sensor in the Fan Pack Module to set fans to
maximum speed.
Pinhole switch that resets the RMM power. Switching information is not affected. RMM
configuration information is not affected.
Pinhole switch that resets the RMM configuration information to the default configuration
settings, and then resets the RMM power. See Table 8 on page 56 for a list of defaults.
Switching information is not affected.
Bi-color LED indicates RMM Mode
• Green = Primary
• Yellow = Secondary
• Off = Standby
Bi-color LED indicates IP address assignment mode
• Green = DHCP
• Off = fixed IP address
RMM Hardware
Module RMM Status
Mode Switch
Fan Mode
Switch
Description
Switches
LEDs
R Series Data Center Products User's Guide, Rev. B
Reset Switch
RMM Status LEDs
RMM MODE
DHCP
DC POWER
LEDs
HEALTH
