Network Planning and Site
Preparation

Rack and Cabinet Requirements

R Series Data Center Products User's Guide, Rev. B
Before installing the components of the ClearCube Architecture it is very important to
properly prepare the site where you will install the chassis and PC blades. This
chapter provides important information on how to plan for installation.
Figure 10 Standard 19" Rack (left) and Standard 19" Cabinet
Figure 10 shows the two most frequently used structures for holding ClearCube
chassis. A standard 42U rack or cabinet can hold as many as 14 chassis.
Network Planning and Site Preparation • 27
