Symbols – English
6 • Introduction
Symbols are used on the equipment to convey specific information to the operator and
service person. It is important to understand the intended meaning of these symbols.
Below are the graphical symbols that are used on ClearCube Technology, Inc.
Products and their meaning.
Refer to Manual
Used on the equipment's rating label to direct the operator or service person to
the manual for additional information.
Shock Hazard
This symbol indicates the presence of electric shock hazards. Enclosures
marked with these symbols should only be opened by qualified service person-
nel. Refer to the manual for additional information.
Power
Identifies the soft-start switch located on front of the blade, used to power the
blade on and off.
Fuse
Located on equipment rating label. Symbol is accompanied with the specifications
needed for replacement. Only qualified technicians should perform this operation.
Protective Earth Terminal
This symbol identifies the location of the protective earth terminal on the equip-
ment. This terminal is used to connect the protective earth conductor of the
power cord to the building's electrical distribution system's ground.
Ground Bond Terminal
This symbol identifies the location ground bond terminal. This terminal is used
to connect the ground bonding conductor, or the combination of conductive
parts to earth ground for safety purposes.
Equipment Protection Class II
May be located on the power adapter's rating label. Indicates that equipment is
double insulated from hazardous voltages. Not to be confused with "Class 2"
that is a US National Electrical Code (NEC) circuit classification.
These same symbols are used within this document where appropriate to indicate
situations that merit checking this or another manual, or situations that could result in
damage to equipment or physical injury.
