REQUIREMENTS OF INSTALLATION LOCATION
The machine must be installed meeting the minimum distances specified below to guarantee the proper operation and
maintenance access of the machine.
A
Working area in front of machine - in (mm)
B
Maintenance area behind machine - in (mm)
C
Width - in (mm)
D
Depth - in (mm)
E
Height - in (mm)
F
Distance between machines - in (mm)
G
Minimum distance above machines - in (mm)
B
®/™ ©2021 Unity Laundry Systems. All rights reserved.
UTS40
UTS62
39.4 (1,000)
39.4 (1,000)
31.5 (800)
31.5 (800)
34.6 (880)
45.4 (1152)
34.2 (870)
40.9 (1038)
55.1 (1,400)
58.4 (1,484)
0.75 (19)
0.75 (19)
36 (914)
36 (914mm)
G
E
A
F
C
Part. 14000001 Rev. 04//2021
