COIN MECHANISM - VENDED MODEL ONLY
13.3

MENU SETTINGS

INDICATION DESCRIPTION
tH Teaching Mode
Pr Price
Cn Coin Value
Coin / Token
tL Acceptance Toler-
ance Number
dL Delete
To Enable Inhibit
In
Mode
13.4

EXAMPLE OF SETTING / TEACHING 50 CENTS TO CHANNEL 2

To set 50 cents on Channel 2 (c2):
1. Enter the setting mode.
2. Select "tH" from the menu and press "Ent" to confirm.
3. The display will show "c1." Use "+" to look for "c2" and press "Ent" to confirm.
4. The original coin value will appear on the display. Keep pressing "+/-" and stop at coin value "5." Press "Ent" to confirm.
5. The display will show "00" with blinking. Insert 6 pieces of 50 cents coin. The menu will automatically return to "c2." (use
multiple 50 cents coins to maximize the coin acceptance rate)
6. Press "Esc" for more than 2 seconds to exit and press "Esc" again for more than 2 seconds to return to the setting mode.
13.5

EXAMPLE OF CHANGING THE PRICE

To change price from 1 (default value) to 5:
1. Enter the setting mode.
2. Navigate to "Pr" by using "+/-" and press "Ent" to confirm.
3. The original price "1" will appear on the display, use "+" to search for "5" and stop.
4. Press "Ent" to confirm. The menu will return to "Pr."
5. Press "Esc" for more than 2 seconds to save to exit.
Note: Changing the price value will affect the coin slot pulse output. Refer to "Understanding Coin Value/ Price Vs
Pulse Output" for more information.
42
Part. 14000001 Rev. 04//2021
(STEP 2)
Select Channel: From c1
to c12
Set Price:
Select Intended Channel
(c1 to c7)
Select Channel number
from c1 to c12 to adjust
the tolerance
Select Intended Channel
(e.g., c6)
No Inhibition
(STEP 3)
Set Coin Value: Min 0, Max
255
Default : 1 Min 0 , Max 255
Set New Coin Value Min 0,
Max 255
Select Tolerance: t1 and t2:
Diameter t3 to t6 : Material
Enable Channel : 00 Delete
Channel : 01
: no Low Inhibition :Lo High
Inhibition : HI
