TROUBLESHOOTING

15.0 TROUBLESHOOTING
FAILURE
· No Power
· Circuit Breaker Malfunction
The machine
· Controller Malfunction
does not run
· VFD Malfunction
· VFD Fuse
· The output frequency of VFD is
The drum is not
· Motor failed
rotating at normal
speed
· Bearing failed
· Belt failed
· The drain is clogged
· VFD malfunction
Excessive water
in the laundry
· Low extract speed
· Out-of-balance switch too sensitive
· SHIPPING BRACKETS are not
· The machine isn't installed level
Excessive
· Out-of-balance switch malfunction
vibration during
high extract
· Load is too small / big
· Loose bearing
· Damaged shock absorber
· The door is not tight
Door leakage · The door gasket is damaged
· The door is misaligned
· Water level sensor malfunction
Drum overfilling · Water inlet valve malfunction
· Circuit board malfunction
· No water or the water pressure is
· Clogged water strainer filter
No water in
· Water inlet valve malfunction
· Drain valve malfunction
· Drain valve malfunction
Water leaking
· Hoses leaking
50
Part. 14000001 Rev. 04//2021
CAUSE
wrong
removed
too low
SOLUTION
· Check the circuit breaker, disconnect, and fuse
· Check the wire connection
· Check the interlock switch
· Check whether the power-on LED on the circuit
board is lit, if not, notify the manufacturer
· Check the controller for VFD alarm code
· Check VFD
· Check the voltage of the motor
· Check out-of-balance switch
· Check with hand whether the inner drum is turning
and remove foreign objects
· Check the belt or replace if necessary
· Check the drain valve and remove obstruction
· Rebalance the load
· Contact Unity 1-800-484-3013
· Remove transport brackets
· Level machine
· Check out-of-balance switch and replace it if
necessary
· Ensure the load is between 7-35 lbs
· Replace shock absorber
· Contact Unity 1-800-484-3013
· Replace the door gasket
· Check and adjust door hinges
· Check water level line/tubing, adjust or replace if
necessary
· Check the water inlet and dispenser valves, replace
if necessary
· Replace main relay PCB
· Check external water supply
· Clean water strainer filter
· Check the water inlet valve, replace if necessary
· Check drain valve, replace if necessary
· Check drain valve, replace if necessary
· Check hoses and hoses connections, replace or
tighten if necessary
