VENDED CONTROLLER OVERVIEW
4.0
CONTROLLER VENDED
The controller is specially designed for the operation of the washer for the self-service vended market. The controller provides
automatic operation of the washer. In automatic mode, the auto program will be initiated by a single touch of the [Start] key.
The machine will run automatically to the end of the selected cycle. The controller provides easy operation for the user and
also provides access to all the menus to setup, to diagnosing error codes, and to check the status and health of the machine.
Note: the key function as shown in the figure.
The hot, warm, cold and start buttons are used to navigate the washer menus.
Hot - Up Arrow
Warm - Down Arrow
Cold - Escape
Start - Enter
ICON
[HOT] button
Press this button to select hot water temperature.
[WARM] button
Press this button to select medium water temperature.
[COLD] button
Press this button to select cold water temperature.
[Start] button
Press this button to start executing the selected wash cycle.
22
Part. 14000001 Rev. 04//2021
FUNCTION
MENU NAVIGATION
↑
↓
Escape
Enter
®/™ ©2021 Unity Laundry Systems. All rights reserved.
