1301T
1301M
3.3.

CHARACTERISTICS

3.3.1. Main technical characteristics

 TFT colour touch screen display 4,3'', resolution 480x272.
 Static or dynamic measurements (Max, Min, Max-Min, Average, Median)
 Analogue or digital display
 2 measurement configurations (2 characteristics)
 Possibility to select automatically the characteristic by moving a probe or by
pressing a key.
 Relative or absolute display by pressing a key
 Display resolution (from 1 to 5 decimals)
 Metric (mm or µm) or Imperial (Inches) measurement
 RS232 port for communication with a PC
 USB port for communication and/or power supply
 Optional connection of I/O module
 Measurement transfer by pressing a key, footswitch input or retro-command on
the RS232 port.
 Operating temperature : : +15°C to +30°C
 Power supply from 85 to 265 VAC by using the supplied main transformer (or by
connecting it directly on your PC USB port.
 Relative humidity : maximum 80%
 Dimensions : width 136 mm, height 120 mm, depth 105 mm
 Mass : 600 grams (700g with the power supply)
Page 6
Heidenhain with a 11µA or 1Vpp output
2 inductive probe with a Tesa
compatibility
2 x inductive probe from Mahr
M3
