M3
5.4.

CONFIGURATION

After clicking on this button, the below window appears.
This window allows configuring the communication settings of your M3
Footswitch function
- « Preset » Calibration
- « transfer » : send the measurement to the RS232 or
USB
- « part » : change the active part (part 1 / part 2)
- « Init Dyn » : start dynamic measurement (min, max...)
- « zero » : Set the displayed value at zero
- « hold » : freeze the measuring screen, the "clear"
button becomes yellow when the screen is frozen
- "screenshot" : generate a BMP file on the USB stick
when the footswitch is pressed.
When 2 functions are programed, a pressure on the
pedal makes them happen one after each other.
Choice of the transfer
mode: RS232, USB
stick or Keyboard
(refer chapter 7 and
8).
Language
selection. Other
languages can be
installed on
demand.
