6.4.
Display mode without tolerance
This display mode is very adapted to be used with incremental probes like
Heidenhain.
This mode (see chap. 5.2) allows to display only the numerical value, without
tolerance indication.
It is also possible to change the preset value (calibration) directly from this screen.
Press on the value as shown on the below picture, an input the new value with the
keyboard.
If the double display mode is selected, the 2 characteristics can move together, but
only 1 is active.
The lateral buttons have an effect only on the active characteristic.
For selecting the active characteristic, press on it and the top of the box will become
green.
Page 60
The lateral
button have an
effect only on
the active
characteristic
M3
