Front Wheel
Ensure the safety precautions listed in the page
127 are followed properly.
Removal
• Carefully place the motorcycle in auxiliary stand
(paddock stand ref. page 161).
• Loosen the left side clamping screws (1) and (2)
(ref. Fig. 60).
• Remove the locking screw (3) (ref. Fig. 61).
• Loosen the right side clamping screws (4) and (5).
• Slightly press the quick-release axle (6) inward for
a better grip on the right side.
142
2
1
Fig. 60
3
4
5
• Support the front wheel and slowly pull out the
quick-release axle (6) from the left side (ref. Fig.
62).
6
8
9
Fig. 61
Fig. 62
