• Adjust the LH side projector lamp adjuster (E)
clockwise (Downward) or in anti-clockwise
(Upward) and match the low beam cut-off line to
the marking line (F) (660 mm) on a vertical wall or
screen. (ref. Fig. 43 & 44)
• Both the projectors low beam cut-off line should
match with the marked line on the screen or wall.
Note
Head lamp aiming to be done with the unloaded vehicle
only.
Both the projector lamps
independently.
The adjustment levels mentioned is for solo riding
condition. For dual riding condition, the head lamp beam
may be adjusted as per need for better visibility.
Warning
Do not stare at LED head lamp beam to avoid damage
to the eyes.
should be adjusted
