  • Page 1 WELCOME TO THE #UNSCRIPTED LIFE! OWNERS MANUAL...

  • Page 3: Table Of Contents

    CONTENTS CONTACT(S) FOR SUPPORT FOREWORD SAFETY INFORMATION NOTICE RUNNING-IN INFORMATION ANTI-LOCK BRAKING SYSTEM SAFE RIDING TIPS KNOW YOUR TVS RONIN RIDING YOUR TVS RONIN MAINTENANCE WARRANTY AND SERVICES EXPRESS SERVICE EXPERT ON WHEELS PICKUP AND DROP TECHNICAL SPECIFICATIONS GENERAL INFORMATION...

  • Page 4: Contact(S) For Support

    Email : customercare@tvsmotor.com Disclaimer : TVS Motor Company or any of its officials / Authorized Main dealer / Authorized Dealer do not ask customers for bank / card / wallet details / authentication. In case you face any such claim, please report to the relevant local authorities immediately.
  • Page 5 CONTACT AT OUR AREA OFFICES TAMILNADU-1, 3 & 4 KARNATAKA-1, 2 & GOA MAHARASHTRA-3 & CHATTISGARH 1. TVS Motor Company Limited 4. TVS Motor Company Limited 7. TVS Motor Company Limited V Floor, Gee Gee Universal, No. 600, Anand Surya, 2nd Floor, No.
  • Page 6 MADHYA PRADESH-1 & 2 PUNJAB & CHANDIGARH WEST BENGAL 9. TVS Motor Company Limited 12. TVS Motor Company Limited 15. TVS Motor Company Limited No. 211-212, 2nd Floor, 4th Floor, Royal Business Park, Ground Floor & First Floor, Chinar Incube Business Centre, Chandigarh Ambala Highway, 133 A.
  • Page 7 ORISSA & JHARKHAND 17. TVS Motor Company Limited No. 303, 3rd Floor, Creative Plaza, Rasulgarh, Bhubaneshwar - 751 010. Phone : 0674-2580019 Email : AO.Bhubaneshwar@tvsmotor.com NORTH EAST STATES 18. TVS Motor Company Limited 147 , Udayan, Ganesh Guri, Opp. Punjab National Bank, R G B.

  • Page 8: Foreword

    FOREWORD Welcome to your new story! A story in which you will use your new TVS RONIN to explore the many facets of life. Whether it’s a daily ride, a weekend getaway, or a long and exciting tour, your TVS RONIN is built to take you, wherever your heart pleases.

  • Page 9: Safety Information

    SAFETY INFORMATION Operating this vehicle safely is an important responsibility of the rider. To help you make decisions on safety, we have provided necessary operating procedure and other information in the owner’s manual. This information alerts you on potential hazards that could hurt you or others. Since it is not possible to warn you about all the hazards associated with operating or maintaining the vehicle, you must use your own judgement.

  • Page 10: Notice

    This Owner‘s Manual contains a host of useful information. Please take the time to read this manual before you ride your new TVS RONIN. Get familiarised with the operation of your motorcycle for maximum safety and pleasure. The better you know your vehicle, the more pleasure you will experience riding your new vehicle. Ensure that anyone else riding your TVS RONIN does the same.

  • Page 11: Running-In Information

    Caution Replacing the engine cum transmission oil during first service is most important for better life of engine. Always use TVS TRU4 FULLY SYNTHETIC oil (SAE 10W30 API-SL, JASO MA2) for better performance and life. Since your motorcycle is fitted with Evaporative Emission Control System, the motorcycle should not be laid on the floor...

  • Page 12: Anti-Lock Braking System

    ANTI-LOCK BRAKING SYSTEM ANTI-LOCK BRAKE SYSTEM (ABS) Your motorcycle is fitted with an Anti-lock braking system (ABS) which is designed to prevent skidding and help riders to maintain steering control during emergency-stopping situation in dry or wet roads, loose gravels etc. Incase of single channel ABS system, the ABS system is provided only on the front brake whereas dual channel system has the ABS system on both front and rear brakes.
  • Page 13 As soon as the actual circumstances arises, the system reacts instantly and adjusts braking force HECU HECU accordingly to achieve optimum braking. Why does brake pedal / lever pulsate during brake application? Vehicles fitted with ABS uses the conventional brake system during normal operation.
  • Page 14 Always apply both front and rear brake for better performance. The TVS RONIN does an automatic self check every time whenever the ignition lock of the bike is turned ‘ON’. The ABS warning lamp provided on the instrument cluster blinks and informs you that the ABS is under check.
  • Page 15 ABS has an error and your bike should be taken to Use only the recommended make, type and size Š any of our nearest TVS Motor Company Authorised of tyre (ABS tuned with tyre specified by the TVS Main dealer / Authorised Dealer for inspection. Motor Company). DO‘S AND DONT‘S Dont’s...
  • Page 16 ABS error and ABS warning lamp glowing tyres. For repair or replacement please contact continuously. In such cases, just switch ‘OFF’ and switch nearest TVS Motor Company Authorised Main Dealer / ‘ON’ the ignition key once. ABS warning lamp may glow Authorised Dealer.

  • Page 17: Safe Riding Tips

    Riding skill and your mechanical knowledge form the foundation of safe riding practices. We suggest you to practice riding TVS RONIN in a low-traffic condition until you are thoroughly familiar with your vehicle and its controls. Remember practice makes you perfect.
  • Page 18 Posture 4. Look widely instead of gazing at one point. Proper vehicle riding starts with proper posture. 5. Alter your sitting location / posture slightly at intervals during long rides. This will reduce 1. Sit erect on the seat at the position which you fatigue.
  • Page 19 7 . Riding down hills, while cornering and wet roads 2. Even when the brake works normally, if the road close throttle and down shift the gear to take surface is wet or the tyre surface is worn-out, advantage of gearbox and engine which acts as tyres do not take a firm hold on the surface, an additional brake.
  • Page 20 Crankcase emission control system certificate obtained. The engine of new TVS RONIN is equipped with a closed crankcase system to prevent discharging crankcase emissions into the atmosphere. Blow-by gas is returned to the combustion chamber through the air cleaner.

  • Page 21: Know Your Tvs Ronin

    KNOW YOUR TVS RONIN VEHICLE IDENTIFICATION NUMBER The frame and engine serial numbers are the only means of identifying your vehicle from others of the same model and type. They are also required to assist your Dealer for ordering parts or referring to special information.
  • Page 22 LOCATION OF PARTS - HANDLE BAR 1. Instrument cluster 2. Ignition cum steering lock 3. Master cylinder (front) 4. Mode switch 5. Rear view mirror R 6. Engine cut off switch 7 . Front brake lever 8. Throttle grip 9. Hazard switch 10.
  • Page 23 LOCATION OF PARTS - VEHICLE LEFT SIDE 1. Front wheel axle 2. Gear shift lever 3. Side stand 4. Rider foot rest L 5. Center stand 6. Chain inspection window 7 . Pillion foot rest L 8. Rear wheel axle 9.
  • Page 24 LOCATION OF PARTS - VEHICLE RIGHT SIDE 1. Disc plate front 2. Toner ring front 3. Front wheel axle nut 4. Wheel speed sensor front 5. Caliper assembly front 6. Location of spark plug 7 . Gauge oil level 8. Rear brake pedal 9.
  • Page 25 LOCATION OF PARTS - VEHICLE FRONT & REAR FRONT 1. Turn signal lamp front L 2. LED Head lamp assembly 3. Oil cooler 4. Tank guard 5. Position lamp 6. Turn signal lamp front R REAR 1. Turn signal lamp rear R 2.
  • Page 26 CONTROL KEY TVS RONIN comes with a pair of identical control keys. These keys are to operate ignition cum steering lock, fuel tank cap and seat lock. IGNITION CUM STEERING LOCK The ignition cum steering lock enables and disables the electrical circuit and steering lock. There are three positions in the ignition cum steering lock.
  • Page 27 ‘ODO’ will be displayed in the cluster’s display. Incase of connected instrument cluster, the cluster displays the product name ‘RONIN’ followed by a greeting message ‘HAVE A SAFE RIDE’ will be displayed. Wait till the cluster’s display becomes static.
  • Page 28 6. Head lamp high / low beam switch Warning The  head  lamp  low  beam  glows  (low or high beam Failure to switch the turn signal lamp ‘ON’ or ‘OFF’ at the glows based on the switch position) automatically on  right time may lead to an accident. starting the engine.
  • Page 29 HANDLE BAR RIGHT SIDE 1. Engine cut off switch It is used to switch off the engine but to keep other DC system active. If the switch is positioned at ‘ ’, the ignition circuit will be disabled, preventing the engine from being restarted.
  • Page 30 ‘Rain’ modes (refer page no. 36). GEAR SHIFT LEVER UP SHIFT DOWN SHIFT TVS RONIN is equipped with a 5 speed constant mesh transmission. Neutral (N) position of the Caution transmission is indicated by the indiction light ‘ ’ on Never shift gears without disengaging the clutch and the instrument cluster.
  • Page 31 REAR BRAKE PEDAL Caution The rear brake pedal operates a hydraulic circuit (ABS Independent use of rear or front brake reduces the circuit incase of Dual channel ABS) that operates overall braking efficiency. In extreme conditions braking the rear brake system and it is located adjacent to with only rear or front brake may lock the wheel which the right side foot rest.
  • Page 32 INSTRUMENT CLUSTER Non-Connected Type Your TVS RONIN is provided with a fully digital instrument cluster with lots of features and various modes. The connected type instrument cluster has the mobile app for ‘Smart Phones’ and navigation assist etc. The non-connected type comes without mobile app and navigation assist.
  • Page 33 Glows when the head lamp is activated in high beam. indicator start to blink and the vehicle will not get start. In such a condition, please visit the nearest TVS Motor 6. Immobilizer indicator ( Company Authorised Main Dealer / Authorised Dealer.
  • Page 34 6 km/h speed and above in single channel vehicle. If this lamp glows continuously even after reaching the specified speed, have your vehicle checked at TVS Motor Company Authorised Main Dealer / Authorised Dealer (refer page no. 11 for more details).
  • Page 35 11. Gear shift indicator 12. Tachometer The gear shift indicator in the digital display indicates Tachometer indicates the engine speed in multiples the position of the gears. of 1000 RPM (Revolutions Per Minute). Gear shift indicator also alerts the user to ‘up shift’ or ‘down shift’...
  • Page 36 Note If you notice an error message ‘- -’ instead of speed indication when the vehicle is in move, Contact nearest TVS Motor Company Authorised Main Dealer / Authorised Dealer. 15c. Distance to empty (DTE) 15. ODO - Trip A & B - DTE indicators Indicates the approximate distance that can be The procedure for setting ‘ODO’, ‘TRIP A &...
  • Page 37 Note Note DTE is an estimated measure of distance that can be When the ignition switch is turned ‘ON’ with the engine travelled and it is subjected to variation based on riding kill switch ‘ON’ condition, priming noise of fuel pump pattern, road conditions etc.
  • Page 38 This is only a reminder indicator. continues to pop-up till the vehicle is serviced and Customers are advised to keep track and follow the the reminder is reset. Get the vehicle serviced at TVS service schedule. Motor Company Authorised Main Dealer / Authorised...
  • Page 39 20. Ride Modes TVS RONIN has two different ride modes, select the desired ride mode by pressing the mode switch in the right hand switch assembly (refer page no. 26) or by pressing the mode switch of the instrument cluster.
  • Page 40 20a. URBAN mode In ‘Rain’ mode the ABS braking system is modified to suit wet or rainy condition. The ABS intervention is earlier and safe braking will be felt. Note At the end of self-check active ride mode information will be displayed on the LCD segment.
  • Page 41 MODE AND SET BUTTONS Note In case any fault is detected with respect to the ride mode change in the EMS or ABS system, then your motorcycle will operate only in the ‘Urban’ mode after ignition key reset. If conditions for mode change are not successful, A message ‘MODE CHANGE ERROR’...
  • Page 42 Setting the digital display Every press of the ‘Mode’ button changes the display to other mode. Follow the below procedures to change the display to desired mode. If ignition is turned ‘OFF’ when the meter is in ‘ODO’ or ‘TRIP’ meters, then the respective meters will be displayed in the next ignition ‘ON’.
  • Page 43 Clock setting 11. Press the ‘Set’ button again to set minutes and to come out from clock setting. The display can be in any screen. Press and hold the ‘Mode’ button for few seconds till the display enters ‘CLOCK SETTING’. Note The clock time gets synced automatically on pairing your Press the ‘Set’...
  • Page 44 Using the Bluetooth pairing mode the connected has to be forgotten using ‘Forget This Device’ from instrument cluster of ‘TVS RONIN’ can be connected Bluetooth settings in the following manner: ® to your Android™ smart phones and iPhone Bluetooth ®...
  • Page 45 1. In the previous connected iPhone, open the Steps to ‘unpair’ in android Phone: SETTINGS -> BLUETOOTH. If the user needs to connect multiple android Phones 2. Select the instrument cluster, which was with the single instrument cluster, the previous connected previously.
  • Page 46 1. In the previous connected android Phone, open the SETTINGS -> BLUETOOTH. 2. Select the instrument cluster, which was connected previously. 3. Click on the ‘Unpair’.
  • Page 47 ‘Connect icon’ of To pair your Android smart phone or iPhone with the mobile app to establish the connection with your TVS RONIN motorcycle’s connected instrument the cluster. cluster, via Bluetooth, for the first time, follow the procedure as described below: •...
  • Page 48 OS Please remember that, all the smart phones are not (Ex. : MI, Vivo etc.). compatible for pairing with the TVS RONIN motorcycle’s In case of Android phones with Android OS version connected instrument cluster.
  • Page 49 This is the default window when the connected Incase multiple SIM cards are used in smart phone, by instrument cluster of your ‘TVS RONIN’ is connected default, SIM 1’s network provider’s signal strength is with your smart phone using Bluetooth ‘...
  • Page 50 Warning Once the navigation assist is turned ‘ON’, the TVS Motor Company Limited does not recommend display of your TVS RONIN motorcycle’s connected usage of any type of Mobile Hand Held Devices, instrument cluster enters into navigation window and applications / features whether installed or and displays the turn by turn navigation instruction associated with the vehicle which deprives the rider’s...
  • Page 51 Low fuel alert The customer also can chose to reject the request (by pressing the ‘Info switch’ on the handle bar for When the fuel level in the vehicle reached below about 1 sec.). In which case, the previous display will reserve level, the app sends a low fuel alert to the remain.
  • Page 52 Voice assist The connected functionality has come with an additional feature - Voice assistant. With help of the voice assist feature, the rider will be able to access mobile application and instrument cluster through speech. Once the mobile application is connected to the instrument cluster, voice assist feature can be used There are two ways to invoke voice assist in your...
  • Page 53 Wait for a second and start speaking/providing the command, once you hear “Speak now” . The following are the list of intents recognized by voice assist. You can refer page no. 51 for sample commands of each intent: • Greeting command •...
  • Page 54 Voice assist commands and key words S. No. Intent Commands Voice Feedback Hi buddie How are you doing Hi buddie GREETING Hello ‘_____’ Hey buddie Hello friend How u doing Go to Take me to Let's go to Navigate to Navigate me to NAVIGATION Taking you to ‘_____’...
  • Page 55 S. No. Intent Commands Voice Feedback Reset TRIP A Reset TRIP A Data Reset Trip A Info RESET TRIP A MODE Trip A Mode Reset Complete Erase Trip A Clear Trip A Clear Trip A Data Reset TRIP B Reset TRIP B Data Reset Trip B Info RESET TRIP B MODE Trip B Mode Reset Complete...
  • Page 56 S. No. Intent Commands Voice Feedback Show my vehicle Range Show my fuel range How far I can travel DTE MODE DTE Mode Activated Switch to DTE Activate DTE mode Switch to DTE mode Reset DTE Reset DTE Data Reset DTE Info Erase DTE RESET DTE MODE DTE Reset Complete...
  • Page 57 S. No. Intent Commands Voice Feedback Near Near by Taking you to nearest ‘_____’ Near to Nearest My location What is the name of this place Where am i now What is my current location CURRENT LOCATION Show my location You are around ‘_____’...
  • Page 58 S. No. Intent Commands Voice Feedback Last call Who called me last Who called recently CALL LAST You have last call from ‘_____’ Last caller Show my last caller Who is my last caller When did I start my ride What time I start ride When did we start from home / work RIDE START TIME...
  • Page 59 S. No. Intent Commands Voice Feedback Decrease volume Volume down VOLUME DECREASE Volume Decreased Decrease sound Reduce volume SETTING HIGH SPEED Enable high speed alert High speed alert setting enabled ALERT ENABLE SETTING HIGH SPEED Disable high speed alert High speed alert setting disabled ALERT DISABLE Cancel navigation End navigation...
  • Page 60 S. No. Intent Commands Voice Feedback Brightness Increase Brightness up Brightness high Brightness increased / Increase brightness BRIGHTNESS INCREASE Maximum brightness Increase the speedo brightness Increase the brightness Turn up the brightness Increase the brightness Brightness decreased Brightness down Brightness low Brightness decreased / BRIGHTNESS DECREASE Decrease brightness...
  • Page 61 Things not to do while using voice assistant: Note 1. We recommend you not to use the method of The list of commands and intent will be updated invoking voice assist through mobile App while periodically. Please refer to the command list mentioned riding.
  • Page 62 Voice feedback RONIN also has feature of voice feedbacks along with voice assist functionality. Voice feedback feature communicates from vehicle to customer of either critical parameters like fuel level or rider warnings like direction indicators and side stand alert chimes. Some of the features in voice feedback like Turn on Mobile data, GPS signal low will work only in Voice assist mode as shown below: Sl.
  • Page 63 Sl. No. Feature Voice feedback Display in cluster If side stand is in stand down Alert chime -No change- condition If direction indicators is turned ON Alert chime -No change- If the engine temperature is greater Take a Break, your bike is HIGH ENGINE TEMP than threshold value running hot...
  • Page 64 Dedicated smart phone app is available in the Google 10. To generate and store Ride reports. Play and the Apple store for your ‘TVS RONIN’ and 11. To sync the connected instrument cluster clock it can be installed in your Android smart phones and with smart phone clock.
  • Page 65 How to login Note On opening the TVS CONNECT app the following This smart phone app is compatible only for the smart introductory screens will be displayed. phones with Android OS version 8.0 and above, iOS version 11 and above and the BLUETOOTH version 4.0 and above.
  • Page 66 FACEBOOK and Enter the OTP which is received from TVS Motor GOOGLE+ or a tab for creating new account. Company Limited and submit. On submitting the...
  • Page 67 Add vehicle Add vehicle tab allows you to add any of your TVS bikes by entering its chassis number. You can have sample view of the frame number and also you can get help by chatting with us or by E-mailing to us or by calling us.
  • Page 68 Illumination setting 1. Press and hold the ‘Mode’ button for few seconds till the display enters ‘CLOCK SETTING’. 2. Press ‘Mode’ button twice till the display ‘illumination’. 3. Press ‘Set’ button to enter illumination setting. 4. Now Press ‘Mode’ button change the illumination from the range of 20% to 100%.
  • Page 69 COOLING SYSTEM LED HEAD LAMP TVS RONIN is designed with an external oil cooler TVS RONIN comes head lamp combined with front arrangement for optimal engine cooling. position lamp (FPL). FPL glows automatically once the igntion is turned ON and the head lamp glows on The oil cooler is mounted in front of the engine which starting engine.
  • Page 70 If you find any deviation in the head lamp beam focus of TVS RONIN, check the focus by following 4. Start the vehicle and turn head lamp to high beam the procedure given below. If the focus is not within mode.
  • Page 71 FUEL TANK Warning Flush type fuel tank cap (1) is provided in TVS RONIN. Do not smoke while refueling. Do not use cell phones To open the fuel tank cap, lift the protection lid (2), while refueling. Avoid spilling of fuel on the hot engine.
  • Page 72 This vehicle is fitted with Evaporative Emission during opening of fuel tank cap, immediately report Control System (EVAP system with canister). to the TVS Motor Company Authorised Main Dealer / Authorised Dealer. Caution Never fill fuel beyond the fuel tank inlet (1). Filling...
  • Page 73 STANDS Warning TVS RONIN is equipped with a centre (1) and side Park the motorcycle safely on a solid ground. On slopes, stand (2). engage the first gear and park the vehicle in such a way To place the vehicle on the centre stand, hold the that the front wheel faces uphill.
  • Page 74 SEAT Re-assembly The seat lock is located at the left side of the vehicle There are four hooks to lock the seat with frame. near the cover frame L. Ensure to locate these seat hooks into the frame guides and gently push the seat little foreword and Removal press at rear end till you hear the ‘click’...
  • Page 75 It is recommended to use the tool kit in case of any 1. Grip driver emergency only. It is always advisable to take your vehicle to TVS Motor Company Authorised Main Dealer 2. Bit (+) (-) / Authorised Dealer. 3. 12 x 14 open end spanner...
  • Page 76 COVER FRAME R Caution Make sure that the cover frame is locked securely in position after installation. Removal Cover frame R is provided to access the battery and rear disc brake master cylinder. This cover can be opened in the following manner: 9.
  • Page 77 ADJUSTMENTS Front brake lever - Adjustment* Clutch lever - Adjustment* TVS RONIN comes with an adjustable front brake lever. There are three positions provided for you to TVS RONIN comes with an adjustable clutch lever. adjust the lever to suit your palm size. The lever can...
  • Page 78 2. Use the USB, if approved standard USB cable Caution used for charging mobile. Do not try doing any adjustment while riding as it may 3. Do make sure the flap is not damaged while lead to fatal accident. opening / inserting the USB cable. Do not use any tool or objects to turn the position DON’Ts adjuster.

  • Page 79: Riding Your Tvs Ronin

    RIDING YOUR TVS RONIN PRE RIDE INSPECTION Check the following items before riding ITEM WHAT TO CHECK FOR Engine cum transmission oil Availability of oil upto the level (page no. 80) Fuel Enough fuel for the planned distance of running Tyres Correct pressure (page no.
  • Page 80 STARTING THE ENGINE SETTING THE VEHICLE IN MOTION As you turn the ignition switch to the ’ON’ position, 1. Press the clutch lever and engage first gear by the instrument cluster and the warning lights will go pressing the gearshift lever down. through the self-diagnostic cycle.
  • Page 81 Riding on hills/gradients Warning When climbing steep hills, the motorcycle may begin Reduce speed to a safe limit before turning / cornering. to slow down and show lack of power. At this point, Do not apply brake while turning / cornering. Do not the rider should shift to a lower gear so that the disengage clutch before braking.
  • Page 82 FUEL RECOMMENDATION Caution Use only BS VI petrol with minimum RON 91. Never mix oil and petrol in the fuel tank. Always fill fuel BS VI petrol containing upto 10% of ethanol by from reputed and reliable fuel stations. volume can be used. CHECKS AND TIPS FOR IMPROVING FUEL Higher ethanol content in petrol can ECONOMY...
  • Page 83 If any fuel leak from tank is suspected, tow the vehicle overheating of engine. to the nearest TVS Motor Company Authorised Main If the condition persists even after adjusting the Dealer / Authorised Dealer.
  • Page 84 Check the tyre pressure regularly (weekly) and inflate Note it to the recommended pressure (refer page no. The on-road mileage of TVS RONIN is dependent on 97). Never use tyres which are worn out beyond several factors like road condition, quality of fuel, riding the permissible limit.

  • Page 85: Maintenance

    Cylinder head, steering components, suspension, chain and wheel components etc., are key items and require very special and careful servicing. TVS Motor Company Limited strongly recommends that the jobs as per the maintenance schedule be performed by your TVS Motor Company Authorised Main Dealer / Authorised Dealer.
  • Page 86 PERIODIC MAINTENANCE SCHEDULE (months or km whichever occurs earlier) After free In free service service Remarks SERVICE Every 750 - 1000 5500 - 6000 11500 - 12000 6000 km 12 months PERIOD FROM THE DATE OF SALE 30 - 45 days 6 months 6 months ITEMS...
  • Page 87 After free In free service service Remarks SERVICE Every 750 - 1000 5500 - 6000 11500 - 12000 6000 km 12 months PERIOD FROM THE DATE OF SALE 30 - 45 days 6 months 6 months ITEMS ACTIVITY All bulbs, horn and switches Inspect for proper functioning Battery voltage and terminals Inspect...
  • Page 88 RECOMMENDED LUBRICANTS APPLICATION MANUFACTURER BRAND 1300 ml (after draining) TVS TRU4 FULLY SYNTHETIC oil Engine cum transmission oil TVS Motor Company 1500 ml (after disassembly) SAE 10W30 API-SL, JASO MA2) SHOWA SS-47G RH front fork - 500 ± 2 cc Front fork oil –...
  • Page 89 2. Check the battery voltage. If the voltage measured Incase of any abnormality or for removal of the is less than 12.4 Volts, charge the battery using battery from the vehicle, contact TVS Motor Company TVS Motor Company Limited recommended Authorisd Main Dealer / Authorised Dealer.
  • Page 90 Recommendations to maintain battery health (positive negative wires) disconnected and fasteners can be secured during prolonged parking conditions with battery terminals.* While your vehicle is parked for prolonged duration, battery continues to discharge and if left unattended 2. During Storage can get completely discharged.
  • Page 91 • Recharge battery if voltage is below 12.4 FUSE REPLACEMENT Volts. The electrical components of your motorcycle are protected by five fuses. Out of which four fuses • Valve Regulate Lead Acid (VRLA) / Lead Acid are housed inside a fuse box and located inside the batteries are prone to water damage.
  • Page 92 7 . Close the fuse case and re-fix case. 8. Turn ‘ON’ the ignition lock and check for proper functioning of electrical and ABS system. lncase if the fuse fails again, consult the nearest TVS Motor Company Authorised Main Dealer / Authorised Dealer.
  • Page 93 SPARK PLUG Visually inspect the spark plug gap. The gap should be 0.8 to 0.9 mm. If the gap is found to be more, 1. Wipe and clean the dust and mud around the replace the spark plug with a new one. spark plug mounting to avoid their entry inside the cylinder.
  • Page 94 7 . If the oil level is below the minimum level, top performed when the engine is in cold condition, after up with TVS TRU4 FULLY SYNTHETIC oil (SAE placing the motorcycle in center stand with front 10W30 API-SL, JASO MA2) upto the maximum wheel touching the ground.
  • Page 95 Adjust the clutch lever free play only when the engine is cold. After adjusting free play properly, if there is a clutch slip or there is difficulty in shifting gear, visit your TVS Motor Company Authorised Main Dealer / Authorised Dealer for rectification.
  • Page 96 REAR SHOCK ABSORBER TVS RONIN is provided with dual rated, 7 step adjustable, gas filled rear shock absorber to meet different road and load. SOFT HARD Note During the time of delivery of the motorcycle, the rear suspension is adjusted to the standard configuration.
  • Page 97 (4) and the toner ring (5) to the front wheel. Also TVS Motor Company Authorised Main Dealer / you can observe a high pressure hose connecting Authorised Dealer for topping-up the brake fluid, the master cylinder to the HECU of ABS system air bleeding and other brake related inspections.
  • Page 98 (5) and toner ring (6)* to the rear wheel. Two spongy or ineffective due to air entry, contact high pressure hoses connecting the master cylinder TVS Motor Company Authorised Main Dealer / to HECU* and HECU* to the caliper (in singal channel Authorised Dealer for topping-up the brake fluid, ABS version high pressure hose is connected directly air bleeding and other brake related inspections.
  • Page 99 Warning Lack of maintenance of the brake system increases the risk of accident. If you notice any malfunction in brake system contact nearest TVS Motor Company Authorised Main Dealer / Authorised Dealer. Caution Replace the brake pads as a set, if the wear indicator...
  • Page 100 TYRES* Tyre tread condition Operating the vehicle with excessively worn tyres Tyre pressure: will decrease riding stability and can lead to loss of Check the tyre pressure atleast once in a week if not control. It is recommended to replace the tyre when more frequently.
  • Page 101 Tyre puncture Caution TVS RONIN is fitted with a tubeless tyre on both front Side walls of the tubeless tyres which are in contact with and rear wheel. lncase of any puncture / tyre damage the wheel rim are only seals the air inside the wheel it is advised to visit nearest tyre manufacturer Dealer assembly.
  • Page 102 Tyre Maintenance Tips Inflation Pressure Check - Condition Within Within 1 km 5 km Note If vehicle is in hold condition for long time • Need movement of vehicle to avoid particular spot of tyre not to touch the ground for more than week time. •...
  • Page 103 Shake the TVS TRU SPRAY chain cleaner bottle well. • Rotate the rear tyre so as the chain, front and rear sprockets rotate along with it. Apply TVS Warning TRU SPRAY chain cleaner front and sideways. Riding with improperly adjusted chain / high slackness •...
  • Page 104 3. After the chain is completely dry, apply TVS TRU4 Chain Lub by rotating the rear wheel by hand in forward direction. 4. Now, check the slackness of the drive chain (as shown). The slackness of the drive chain should not exceed the limit (maximum 20 ~ 25 mm).
  • Page 105 FRONT WHEEL REMOVAL AND REASSEMBLY Warning 1. Slightly loosen the axle nut (1) Ensure proper seating of disc in the caliper assembly 2. Loosen the left side clamping screws (2) and (3). while reassembling the wheel. 3. Now, remove the axle nut along with a washer. Ensure to re-fix the right spacers at both the sides of 4.
  • Page 106 6. During re-assembly, engage the drum sprocket REAR WHEEL REMOVAL AND REASSEMBLY with the wheel along with the drive chain and 1. Remove the wheel hugger rear. then assemble the wheel into swing arm. 2. Remove the axle nut (1) along with the washer 7 .
  • Page 107 3. Empty the fuel tank. it may fall. 4. Remove the spark plug and feed in several drop During storage, the battery must be recharged on a TVS of engine cum transmission oil through spark plug Motor Company recommended battery charger atleast hole.
  • Page 108 1. Complete tool kit / first aid kit required. 2. Recommended spark plug one number. 3. Fill the engine cum transmission oil (TVS TRU4 3. Throttle and clutch cables one number each. FULLY SYNTHETIC - SAE 10W30 API-SL, JASO B) Precautions to be taken for the journey: MA2) and check the oil level using the gauge.
  • Page 109 13. Lubrication of all items mentioned in the periodic maintenance schedule. 14. Intactness of EVAP system hoses and canister. 15. Any other job as necessary. 16. Have your vehicle checked at any TVS Motor Company Authorised Main Dealer / Authorised Dealer.

  • Page 110: Warranty And Services

    TVS Motor Company Limited (‘the Company’) give this warranty with respect to the TVS RONIN manufactured by the Company. While the Company has taken every care to maintain quality in the manufacture of the TVS RONIN, the above said warranty is subject to other terms of warranty: ...
  • Page 111 Authorised Main Dealer / Authorised Dealer the Service Handbook for the concerned vehicle for verification of relevant details. 8. This is the only warranty given by the Company for the TVS RONIN. No employee, Dealer or other person is authorised to extend or enlarge this warranty.
  • Page 112 List of parts not covered under warranty ITEM WHAT TO CHECK FOR Normal Maintenance Operations Engine tune-up, decarbonizing, fuel system cleaning, oil changes, head light focusing, fastener retightening, ignition timing, clutch and brakes as well as other normal adjustments. Wear & Tear items Chain, sprockets, clutch and brake linings, fasteners, shims, washers, oil seals, gaskets, O’...
  • Page 113 Vehicles on which any warranty service including scheduled paid service is not availed when it falls due (at TVS Motor Company Authorised Main Dealer / Authorised Others Factors Dealer).
  • Page 114 SERVICE INFORMATION There are eleven services for TVS RONIN during warranty period. Of these, first three services are free services for which labour charges are free. In addition to these three free services, we have a scheme of eight pay services. For keeping the maintenance track of your vehicle, a free and pay service record sheets are attached with this Service Handbook.
  • Page 115 PLANNED SERVICE SCHEDULE (kms or month whichever of the two occurs early) SL.NO. SERVICE TYPE MONTHS 1st Service Free 750 ~ 1000 30 ~ 45 days 2nd Service Free 5500 ~ 6000 3rd Service Free 11500 ~ 12000 4th Service 17500 ~ 18000 5th Service 23500 ~ 24000...

  • Page 116: Express Service

    EXPRESS SERVICE … Get your vehicle serviced in 1 hour at no additional cost. Contact your nearest Dealership for details. … Facility available at selected Dealerships only. Terms and conditions apply...

  • Page 117: Expert On Wheels

    EXPERT ON WHEELS Busy Life? Easy Servicing! Now, service your bike anywhere, anytime. Service the vehicle at your door step. Available for regular maintenance or breakdown service only. Offered at nominal convenience charges. … Contact your nearest Dealership for details. …...

  • Page 118: Pickup And Drop

    PICKUP AND DROP Busy Life? Easy Servicing! Now, service your bike anywhere, anytime. Service the vehicle at your door step. Available for regular maintenance or breakdown service only. Offered at nominal convenience charges … Contact your nearest Dealership for details. …...

  • Page 119: Technical Specifications

    TECHNICAL SPECIFICATIONS TVS RONIN DESCRIPTION Single channel ABS Dual channel ABS TVS MOTOR COMPANY LIMITED MANUFACTURER P .B. No1, Bythahalli, Kadakola post, Mysore - 571 311, India. ENGINE Type Single cylinder, 4 stroke, fuel injection, oil cooled OHC Cylinder bore...
  • Page 120 TVS RONIN DESCRIPTION Single channel ABS Dual channel ABS TRANSMISSION Clutch Wet - multiplate type Gear shift pattern 1 down and 4 up Primary transmission Helical gears Secondary transmission Chain and sprockets GEAR RATIO I gear 2.917 II gear 1.857 III gear 1.333...
  • Page 121 TVS RONIN DESCRIPTION Single channel ABS Dual channel ABS CHASSIS Overall length 2040 mm Overall width 805 mm Overall height 1170 mm Sear length 795 mm Ground clearance (unladen) 181 mm Kerb weight (with toolkit and 90% of fuel) 159 kg...
  • Page 122 TVS RONIN DESCRIPTION Single channel ABS Dual channel ABS BRAKES Front Hand operated, 300 mm petal disc Rear Foot operated, 240 mm petal disc TYRE Front tyre size 110 / 70 - 17 (Tubeless) Rear tyre size 130 / 70 - 17 (Tubeless) Front tyre pressure* 1.75 kg/cm²...
  • Page 123 TVS RONIN DESCRIPTION Single channel ABS Dual channel ABS ELECTRICAL Ignition system ECU - 3D Ignition timing map Spark plug BOSCH - UR4KE Spark plug gap 0.8 to 0.9 mm Battery type VRLA (MF) 12V, 6Ah Generator (flywheel magneto) 12V, 335W...
  • Page 124 BS VI petrol with minimum RON 91 (containing upto 10% of ethanol by Fuel volume) Engine cum transmission oil grade TVS TRU4 FULLY SYNTHETIC OIL (SAE 10W30 API-SL, JASO MA2) 1300 ml (after draining) Engine cum transmission oil qty 1500 ml (after disassembly)

  • Page 125: General Information

    GENERAL INFORMATION Dear Customer, It is mandatory under the Motor Vehicles Act to insure all motor vehicles. No motor vehicle can be used in a public place without a valid policy of insurance issued by an authorised insurer. Driving a motor vehicle without any such insurance is an offense under Motor Vehicles Act.
  • Page 127 TVS Motor Company Limited, P.B. No. 4, Harita, Hosur - 635 109, Tamil Nadu, India. Tel: +91 (4344) 276878 / 277311. http:/ /tvsmotor.com/tvs-ronin...
