FOREWORD
Dear Racer,
Thank you for choosing the TVS Apache RTR 200 Fi 4V.
This race machine wins the race to the future with futuristic technology and a revamped aesthetic. It features new
decals, an LED headlamp, refreshed mirrors, a secure wave bite key with over 9,000 combinations, high performance
radial tyres, a refreshed colour for the engine case, and convenient feather touch start technology.
The performance machine also comes with a 1st-in-class Race Tuned Slipper Clutch technology & Dual-Channel ABS
with RLP (Rear wheel Lift-off Protection). The Slipper clutch enables quick downshifts to attack every corner on the track
while the ABS with RLP offers quick detection and recovery of the wheel lock achieving superior braking performance.
There's always a deep connection between man and race machine. The TVS Apache RTR 200 Fi 4V takes that
connection to another level, with TVS SmartXonnect – a Bluetooth based connection between your smartphone and
race machine that provides call and SMS notifications, turn-by-turn navigation, and comprehensive racing statistics to
give you a winning edge.
As a proud owner of the TVS Apache RTR 200 Fi 4V, you are now part of the 4 million strong TVS Racing family.
This manual explains the features and operations of your TVS Apache RTR 200 Fi 4V. Please read it carefully and follow
the instructions to enjoy the ultimate racing experience. To prolong your journey on the TVS Apache RTR 200 Fi 4V, we
urge you to get your services only at TVS Motor Company Distributor, Dealers or Authorized Service Centers.
Here's your new lap on the Apache RTR 200 Fi 4V.
TVS MOTOR COMPANY LIMITED
I

Advertisement

loading
Need help?

Need help?

Do you have a question about the APACHE RTR 200 Fi 4V and is the answer not in the manual?

Questions and answers

Summary of Contents for TVS APACHE RTR 200 Fi 4V

  • Page 1 As a proud owner of the TVS Apache RTR 200 Fi 4V, you are now part of the 4 million strong TVS Racing family. This manual explains the features and operations of your TVS Apache RTR 200 Fi 4V. Please read it carefully and follow the instructions to enjoy the ultimate racing experience.
  • Page 2 This Owner's Manual contains a host of useful information. Please take the time to read this manual before you ride your new TVS APACHE RTR 200 Fi 4V. Get familiarised with the operation of your motorcycle for maximum safety and pleasure.
  • Page 3 SAFETY INFORMATION Operating this vehicle safely is an important responsibility of the rider. To help you make decisions on safety, we have provided necessary operating procedure and other information in the owner's manual. This information alerts you on potential hazards that could hurt you or others. Since it is not possible to warn you about all the hazards associated with operating or maintaining the vehicle, you must use your own judgement.
  • Page 4: Table Of Contents

    CONTENTS Running-in information Antilock braking system Safe riding tips Know your TVS Apache RTR 200 Fi 4V Riding your TVS Apache RTR 200 Fi 4V Maintenance Service record sheet Technical specifications...
  • Page 5: Running-In Information

    Timely performance of the first free service will ensure optimum service life and performance from the engine. Caution Replacing the engine cum transmission oil during first service is most important for better life of engine. Always use TVS TRU4 FULLY SYNTHETIC oil (SAE 10W30 API-SL, JASO MA2) for better performance and life.
  • Page 6: Antilock Braking System

    ANTI-LOCK BRAKING SYSTEM Anti-Lock Brake System (ABS) Your motorcycle is fitted with an Anti-lock braking system (ABS) which is designed to prevent skidding and help riders to maintain steering control during emergency-stopping situation in dry or wet roads, loose gravels etc. Incase of single channel ABS system, the ABS system is provided only on the front brake whereas dual channel system has the ABS system on both front and rear brakes.
  • Page 7 ANTI-LOCK BRAKING SYSTEM As soon as the actual circumstances arises, the system reacts instantly and adjusts braking force HECU accordingly to achieve optimum braking. Why does brake pedal / lever pulsate during brake application? Vehicles fitted with ABS uses the conventional brake system during normal operation.
  • Page 8 ABS system. Always apply both front and rear brake for better performance. ABS warning lamp The TVS Apache RTR 200 Fi 4V does an automatic self check every time when the ignition switch is turned 'ON'. The ABS warning lamp provided at the speedometer console blinks and informs you that the ABS is under check.
  • Page 9 ● Perform the periodic maintenance as per the ● Do not attempt to correct the toner ring teeth by schedule. bending manually or by using any other method. ● ABS should be serviced only at TVS Motor Warning Company Distributor, Dealers and Authorised Service centers.
  • Page 10 If the ABS warning lamp is still 'ON', then contact Never open HECU on your own, it is a very sensitive part the nearest TVS Motor Company Distributor, Dealers / of ABS and needs to be handled only by the trained Authorised Service Center (applicable only for dual personnel.
  • Page 11: Safe Riding Tips

    Riding skill and your mechanical knowledge forms the foundation of safe riding practices. We suggest you to practice riding TVS Apache RTR 200 Fi 4V in a low-traffic condition until you are thoroughly familiar with your vehicle and its controls. Remember practice makes you perfect.
  • Page 12 SAFE RIDING TIPS Posture Cornering Proper vehicle riding starts with proper posture. When cornering, centrifugal force works in a direction perpendicular to the direction in which the vehicle is 1. Keep your elbows relaxed and flexible. moving. Centrifugal force increases in proportion with 2.
  • Page 13 SAFE RIDING TIPS Causes for poor braking 3. Approximately 60% braking effect is from front brake. Non-usage of front brake causes poor 1. If the brake shoes / pads or drum / disc are worn out braking. or if there is water or oil on them, sufficient friction does not develop and brakes do not work well.
  • Page 14 Crankcase emission control system (after initial 12 months of usage). The engine of new TVS Apache RTR 200 Fi 4V is equipped with a closed crankcase system to prevent discharging crankcase emissions into the atmosphere.
  • Page 15: Know Your Tvs Apache Rtr 200 Fi4V

    KNOW YOUR TVS APACHE RTR 200 Fi4V VEHICLE IDENTIFICATION NUMBER The frame and engine serial numbers are the only means of identifying your vehicle from others of the same model and type. They are also required to assist your Dealer for ordering parts or referring to special information.
  • Page 16 KNOW YOUR TVS APACHE RTR 200 Fi4V LOCATION OF PARTS - HANDLE BAR Horn switch Turn signal lamp switch Clutch lever Pass by switch Rear view mirror L High / low beam switch Info switch Connected instrument cluster Ignition cum steering lock 10.
  • Page 17 KNOW YOUR TVS APACHE RTR 200 Fi4V LOCATION OF PARTS - VEHICLE LEFT SIDE Front wheel axle Gear shift lever Centre stand Side stand Rider foot rest L Pillion foot rest L Rear wheel axle Saree guard Wheel hugger 10. Cover frame L...
  • Page 18 KNOW YOUR TVS APACHE RTR 200 Fi4V LOCATION OF PARTS - VEHICLE RIGHT SIDE Disc plate front Toner ring front Front wheel axle nut Wheel speed sensor front Caliper assembly front Spark plug Gauge oil level Rear brake pedal Rider foot rest R 10.
  • Page 19 KNOW YOUR TVS APACHE RTR 200 Fi4V LOCATION OF PARTS - VEHICLE FRONT AND REAR FRONT Turn signal lamp front L Head lamp assembly Oil cooler Crash guard Turn signal lamp front R Position lamps REAR Turn signal lamp rear R...
  • Page 20 KNOW YOUR TVS APACHE RTR 200 Fi4V CONTROL KEY Your TVS Apache RTR 200 Fi 4V comes with a pair of identical control keys. These keys are to operate ignition cum steering lock, fuel tank cap and seat lock. IGNITION CUM STEERING LOCK The ignition switch enables and disables the electrical circuit and steering lock.
  • Page 21 KNOW YOUR TVS APACHE RTR 200 Fi4V HANDLE BAR LIFT SIDE Warning 1. Info switch Never attempt to move the vehicle when the steering Info switch ' ' is used to cancel an incoming call, is locked, you may lose balance.
  • Page 22 KNOW YOUR TVS APACHE RTR 200 Fi4V Warning Note Failure to switch the turn signal lamp 'ON' or 'OFF' at Pass by system will not work if the head lamp is the right time may lead to an accident. glowing in 'High' beam.
  • Page 23 KNOW YOUR TVS APACHE RTR 200 Fi4V HANDLE BAR RIGHT SIDE 2. Throttle grip 1. Electric starter switch It controls the fuel-air mixture supplied to the engine, which regulates the engine speed. Rotate the throttle Ensure the transmission is in neutral or else press the...
  • Page 24 GEAR SHIFT LEVER Never shift gears without disengaging the clutch and TVS Apache RTR 200 Fi 4V is equipped with a 5 speed releasing the throttle. Failure to comply this will lead to constant mesh transmission. Neutral (N) position of rough shift or jerk while shifting the gears.
  • Page 25 KNOW YOUR TVS APACHE RTR 200 Fi4V REAR BRAKE PEDAL Caution The rear brake pedal operates a hydraulic circuit (ABS Independent use of rear or front brake reduces the circuit incase of Dual channel ABS) that operates the overall braking efficiency. In extreme conditions...
  • Page 26 CONNECTED INSTRUMENT CLUSTER Indicates the vehicle speed in kilometer per hour by Your TVS Apache RTR 200 Fi4V is provided with a fully default whenever the ignition is turned 'ON'. This can be changed to mile per hour. Change the mode...
  • Page 27 If this changing the time format between 12 hour and 24 lamp glows continuously then have your vehicle hour. checked at TVS Motor Company Distributor, Dealers / Authorised Service Centers (refer page No. 04 for more details). Note...
  • Page 28 KNOW YOUR TVS APACHE RTR 200 Fi4V 11. Fuel gauge Digital bars indicates the approximate quantity of fuel available in the fuel tank. There are eight bars to indicate the quantity of fuel available in the fuel tank. Low fuel indication (serial No. 4) starts blinking when the fuel reaches to the minimum safe level 2 .
  • Page 29 KNOW YOUR TVS APACHE RTR 200 Fi4V 12. Odometer / Trip meter 1 & 2 / Lap indicator / 12b. Trip meter High speed indicator / Shortest time indicator Trip meter indicates the trip distance travelled in The procedure for setting each mode is given in page kilometer or mile (as per the preferred settings).
  • Page 30 KNOW YOUR TVS APACHE RTR 200 Fi4V Press the 'Info switch' again to stop the current lap 12d. Notification area timer and to start a new lap. Existing lap timings will A general purpose notification area where, ride mode be displayed as shown below and continue to get information, error information, service due, updated whenever a new lap is started and stopped.
  • Page 31 KNOW YOUR TVS APACHE RTR 200 Fi4V Whenever the vehicle speed crosses the previously 12f. Shortest time indicator achieved high speed, a message 'ACHIEVED HIGH Shortest time indicator records the minimum time SPEED' will be popped-up and a trophy symbol will be...
  • Page 32 KNOW YOUR TVS APACHE RTR 200 Fi4V 13. Ride Modes TVS Apache RTR 200 Fi 4V has three different ride modes, select the desired ride modes by press the mode switch in right hand switch assembly. (refer page no. 19) The modes are explained in the following pages in the below sequence .
  • Page 33 KNOW YOUR TVS APACHE RTR 200 Fi4V 13c. RAIN URBAN In Rain mode the engine and ABS braking system is modified to suit wet or rainy condition. The max speed is limited to 105 Km/h and the ABS intervention is earlier and safe braking will be felt.
  • Page 34 KNOW YOUR TVS APACHE RTR 200 Fi4V 14. Shift RPM indicator / 15. Tachometer / 16. Trip Note F / 17. Gear shift indicator / 18. Service reminder / If conditions for mode change are not successful 19. Low battery indication 'MODE CHANGE ERROR' appears on display.
  • Page 35 KNOW YOUR TVS APACHE RTR 200 Fi4V 16. Trip F Note This function shows the distance travelled when the Gear shifting suggestion changes in different vehicle low fuel indication symbol ( ) starts blinking and fuel operating mode. gauge shows no bar or glows continuously with fuel...
  • Page 36 Note speedometer's self diagnostic cycle when the battery If you notice an error message 'CHECK GEAR charge is too low. Get the battery checked at TVS SENSOR', Contact nearest TVS Motor Company Motor Company Distributor or Dealers / Authorised Distributor or Dealers / Authorised Service Centers Service Centers.
  • Page 37 KNOW YOUR TVS APACHE RTR 200 Fi4V MODE AND SET BUTTONS TRIP A Press MODE Button TRIP B Short press the Mode button to access the following modes: 1. ODO 2. TRIP A 3. TRIP B The Mode (A) and Set (B) buttons are provided to 4.
  • Page 38 KNOW YOUR TVS APACHE RTR 200 Fi4V On long pressing the Mode button, the following Setting the digital display modes can be accessed. Every press of the Mode button changes the display 1. SET mph MODE / SET km/h MODE to other mode.
  • Page 39 KNOW YOUR TVS APACHE RTR 200 Fi4V 3. In 'TRIP B' meter mode, press the Mode button MPH and Km/h setting twice to enter high speed mode. On entering this 1. Ensure the display is in 'ODO' mode. mode, a message 'HIGH SPEED MODE' and last 2.
  • Page 40 Else the clock will be ready for 24 hours format Using the Bluetooth pairing mode the connected selection. instrument cluster of 'TVS Apache RTR 200 4V' can be 5. Press the Mode button to change the hour format connected to your Android™ smart phones and 'AM' or 'PM' or to change the clock to 24 hours iPhone®...
  • Page 41 KNOW YOUR TVS APACHE RTR 200 Fi4V Steps to "Forget This Device" in iPhone: Note Maximum of 3 devices of Android phones can be If the user needs to connect multiple iPhones with the auto-paired with the instrument cluster. single instrument cluster, the previous iPhone has to Only one iPhone can be auto-paired with a single be forgotten using "Forget This Device"...
  • Page 42 KNOW YOUR TVS APACHE RTR 200 Fi4V 1. In the previous connected iPhone, open the First time Bluetooth paring: SETTINGS -> BLUETOOTH. To pair your Android smart phone or iPhone with your 2. Select the instrument cluster, which was TVS Apache RTR 200 Fi4V motorcycle's connected connected previously.
  • Page 43 'OFF' and 'ON', and the application also need to be restarted. Please remember that, all the smart phones are not compatible for pairing with the TVS Apache RTR 200 Fi4V motorcycle's connected instrument cluster. During the search of Bluetooth devices in app, if the...
  • Page 44 8.0 for App to work seamlessly, any battery with your login credential and press 'Connect' icon. optimisation setting to be removed in the TVS Connect app and GPS shall be allowed to run in backround in high accuracy mode.
  • Page 45 This is the default window when the connected Incase multiple SIM cards are used in smart phone, by instrument cluster of your 'TVS Apache RTR 200 Fi 4V' default, SIM 1's network provider's signal strength is is connected with your smart phone using Bluetooth shown in the display of connected instrument cluster.
  • Page 46 The connected instrument cluster displays the total Once the navigation assist is turned 'ON', the display number of missed calls from the smart phone via of your TVS Apache RTR 200 Fi 4V motorcycle's Bluetooth. connected instrument cluster enters into navigation...
  • Page 47 KNOW YOUR TVS APACHE RTR 200 Fi4V Low fuel alert The customer also can chose to reject the request (by When the fuel level in the vehicle reached below pressing the 'Info switch' on the handle bar for about 1 sec.).
  • Page 48 8. To save the last traveled route. vehicle at front and also to drive within the 9. To locate the last parked location of your TVS recommended safe limit of driving. Apache RTR 200 Fi 4V.
  • Page 49 KNOW YOUR TVS APACHE RTR 200 Fi4V How to login On opening the TVS CONNECT app the following introductory screens will be displayed. You can login using your social media logins like FACEBOOK and GOOGLE+ or using your mobile number which has been registered already.
  • Page 50 Home screen of the app opens. Note Please remember that the navigation License has Enter the OTP which is received from TVS Motor to be renewed after 5 years of vehicle purchase Company Limited and submit. On submitting the...
  • Page 51 KNOW YOUR TVS APACHE RTR 200 Fi4V Add vehicle Add vehicle tab allows you to add any of your TVS bikes by entering its chassis number. You can have sample view of the frame number and also you can get help by chatting with us or by E-mailing to us or by...
  • Page 52 RAM AIR DUCT TVS Apache RTR 200 Fi 4V is designed with an TVS Apache RTR 200 Fi 4V is designed with a ram air external oil cooler with stone guard arrangement for duct on the right side of the fuel tank. This ram air duct optimal engine cooling.
  • Page 53 To avoid accumulation of water in the fuel tank, a small TVS Apache RTR 200 Fi 4V comes with a LED head drain hole and a pipe is provided in the fuel tank lid...
  • Page 54 KNOW YOUR TVS APACHE RTR 200 Fi4V Caution Warning Never fill fuel beyond the fuel tank inlet (1). Filling Do not smoke while refueling. Do not use cell phones above the inlet may result in improper breathing of while refueling. Avoid spilling of fuel on the hot fuel tank which leads to difficulty in starting as well as engine.
  • Page 55 KNOW YOUR TVS APACHE RTR 200 Fi4V STANDS Caution TVS Apache RTR 200 Fi 4V is equipped with a centre Do not sit on the vehicle when it is parked on the side stand (1) and side stand (2). stand / centre stand, as your full weight would rest on To place the vehicle on the centre stand, hold the the vehicle's only support.
  • Page 56 KNOW YOUR TVS APACHE RTR 200 Fi4V SEAT Utility box is located under the passenger seat to store The seat lock is located between the rider and the some important items and it provides security to things placed inside. passenger seat assembly.
  • Page 57 It is always advisable to take your supplied along with the vehicle. vehicle to TVS Motor Company Distributor, Dealers / Authorised Service Centers. Tool kit located under the passenger seat. To access...
  • Page 58 Cover frame R is provided to access the battery and CLUTCH LEVER - ADJUSTMENT rear disc brake master cylinder. This cover can be TVS Apache RTR 200 Fi 4V comes with an adjustable opened in the following manner: clutch lever. There are three positions provided for 1.
  • Page 59 KNOW YOUR TVS APACHE RTR 200 Fi4V FRONT BRAKE LEVER - ADJUSTMENT Caution TVS Apache RTR 200 Fi 4V comes with an adjustable Do not try doing any adjustment while riding as it may front brake lever. There are three positions provided lead to fatal accident.
  • Page 60 Suspension TVS Apache RTR 200 Fi 4V front suspension level can be adjusted as per your convenience. Adjust the suspension level as per the load or road conditions. Caution To adjust the suspension level rotate the knob (A)
  • Page 61: Riding Your Tvs Apache Rtr 200 Fi4V

    RIDING YOUR TVS APACHE RTR 200 Fi4V PRE RIDE INSPECTION Check the following items before riding ITEM WHAT TO CHECK FOR Engine cum transmission oil Availability of oil upto the level (page no. 72) Fuel Enough fuel for the planned distance of running Tyres Correct pressure (page no.
  • Page 62 RIDING YOUR TVS APACHE RTR 200 Fi4V STARTING THE ENGINE SETTING THE VEHICLE IN MOTION As you turn the ignition switch to the ’ON’ position, 1. Press the clutch lever and engage first gear by the instrument cluster and the warning lights will go pressing the gearshift lever down.
  • Page 63 RIDING YOUR TVS APACHE RTR 200 Fi4V Riding on hills/gradients Warning When climbing steep hills, the motorcycle may begin Since the engine and exhaust system becomes very to slow down and show lack of power. At this point hot, make sure to park the vehicle in a place where...
  • Page 64 RIDING YOUR TVS APACHE RTR 200 Fi4V FUEL RECOMMENDATION CHECKS AND TIPS FOR IMPROVING FUEL ECONOMY Use unleaded petrol only. Regular checks The petrol should be 85 to 95 octane by research Carry out the periodic maintenance checks as method. Use recommended fuel additives for longer specified in this manual (refer page no.
  • Page 65 Get it replaced at any abnormalities. regular intervals as per the maintenance schedule. Always use TVS TRU4 FULLY SYNTHETIC oil only (SAE Clutch 10W 30 API-SL, JASO Ma2). Increase in engine rpm during acceleration, without increase in road speed indicates clutch slip.
  • Page 66 Note slackness leads to higher fuel consumption (refer page no. 80). Please note that the on-road mileage of TVS Apache RTR 200 Fi 4V is dependent on several factors like Wheels free movement road condition, quality of fuel, riding speed, operation...
  • Page 67: Maintenance

    Service Centers. Periodic inspections may reveal one or more parts that may need replacement. Whenever replacing parts on TVS Apache RTR 200 Fi 4V, it is recommended that you use only the TVS Motor Company Genuine parts. Caution Proper running-in and maintenance are mandatory for making certain that your vehicle is reliable and gives optimum performance at all times.
  • Page 68 MAINTENANCE PERIODIC MAINTENANCE SCHEDULE (months or km whichever occurs earlier) Item Service Service Remarks Every Every 500-750 2500-3000 5000-6000 8500-9000 11500-12000 3000 km 6000 km Period from the date of sale 1 month 3 months 6 months 9 months 12 months Engine cum transmission oil I&T I&T...
  • Page 69 MAINTENANCE Item Service Service Remarks Every Every 500-750 2500-3000 5000-6000 8500-9000 11500-12000 3000 km 6000 km Period from the date of sale 1 month 3 months 6 months 9 months 12 months Throttle grip – – – – Lubricate using grease Clutch and throttle cable play²...
  • Page 70 MAINTENANCE Item Service Service Remarks Every Every 500-750 2500-3000 5000-6000 8500-9000 11500-12000 3000 km 6000 km Period from the date of sale 1 month 3 months 6 months 9 months 12 months All bulbs, horn and switches – Inspect for proper functioning Head lamp beam I &...
  • Page 71 Wheel balancing to be done every 1 year or every 12000 km. In addition, after every tyre puncture repair or tyre replacement, wheel balancing to be done. ** Check for abnormal vehicle jerk / noise while opening the cap / leak. If found any, contact TVS Motor Company Authorised Main Dealer or Authorised Dealer.
  • Page 72 RECOMMENDED LUBRICANTS Application Manufacturer Brand Engine cum transmission oil 1200 ml ( TVS Motor Company TVS TRU4 FULLY SYNTHETIC oil during servicing 1400 ml ( (SAE 10W30 API-SL, JASO MA2) during engine overhaul Front fork oil 329 ± 2 cc...
  • Page 73 1. Remove the cover frame R (refer page No. 55). 2. Check the battery voltage. If the voltage measured The inversion of the battery wires can damage the battery is less than 12.4V, charge the battery using TVS and the recharging system. Motor Company Limited recommended battery...
  • Page 74 MAINTENANCE Good Fuse Blown Fuse FUSE REPLACEMENT The electrical components of your motorcycle are protected by four fuses. Out of which three fuses are housed inside a fuse box and located below the rear seat (passenger seat). One fuse is located below the cover frame near the battery.
  • Page 75 4. Turn 'ON' the ignition lock and check for proper functioning of electrical and ABS system. lncase if the fuse fails again, consult the nearest TVS Motor Company Authorised Distributor or Dealers / Authorised Service Centers. Caution Do not use vehicle by shorting the wires without a fuse.
  • Page 76 MAINTENANCE Visually inspect the spark plug gap. The gap should be ENGINE CUM TRANSMISSION OIL 0.8 ~ 0.9 mm. If the gap is found to be more than the Check the engine cum transmission oil level limit replace the spark plug with a new one. periodically.
  • Page 77 8. If the oil level is below the minimum level, top up with TVS TRU4 FULLY SYNTHETIC oil (SAE 10W 30 The free play of the clutch lever should be 8 ~ 13 mm upto the maximum level mark.
  • Page 78 After adjusting free play properly, if there is a clutch 3. Adjust the clutch cable adjusting nut (1) ‘in’ or ‘out’ slip or there is difficulty in shifting gear, visit your TVS to give sufficient play in the clutch lever.
  • Page 79 MAINTENANCE REAR SHOCK ABSORBER TVS Apache RTR 200 Fi 4V is provided with dual rated, 7 step adjustable, gas filled rear shock absorber to meet different road and load. Warning The rear shock absorber contains highly compressed gas. Do not try to open or disassemble it in any way.
  • Page 80 R along with a wheel speed sensor (3), a disc or ineffective due to air entry, contact TVS Motor (4) and the toner ring (5) to the front wheel. Also you...
  • Page 81 (4)*, a disc or ineffective due to air entry, contact TVS Motor (5) and toner ring (6)* to the rear wheel. Two high...
  • Page 82 Lack of maintenance of the brake system increases Warning the risk of accident. If you notice any malfunction in brake system contact nearest TVS Motor Company The tyre inflation pressure in cold condition and the Authorised Distributor or Dealers / Authorised tyre thread condition are extremely important for the Service Centers.
  • Page 83 (indicated by TWI on the tyre). TVS Apache RTR 200 Fi 4V is fitted with a tubeless tyre on both front and rear wheel. lncase of any puncture / tyre damage it is advised to visit nearest tyre manufacturer Dealer or the tyre repair shops who know the repairing methods of tubeless tyre.
  • Page 84 MAINTENANCE If at all, tyre levers need to be used, the levers should DRIVE CHAIN be free from sharp edges and care should be taken not Proper lubrication and adjustment of drive chain gives to damage the rim and tyre. long service life of the chain.
  • Page 85 3. The slackness of the drive chain should not stopping. exceed the limit (20 ~ 25 mm). 4. If the slackness is found more contact TVS Motor Company Authorised Distributor or Dealers / Authorised Service Centers for adjustment. 5. If the slackness is found within the limit, clean the chain with a dry cloth and lubricate using TRU SPRAY / TRU4 oil.
  • Page 86 MAINTENANCE FRONT WHEEL REMOVAL AND REASSEMBLY Warning 1. Remove the axle nut (1) along with a washer. Ensure proper seating of disc in the caliper assembly 2. Pull out the axle (2) along with a washer and while reassembling the wheel. remove a spacer from both the sides of the wheel.
  • Page 87 MAINTENANCE REAR WHEEL REMOVAL AND REASSEMBLY 6. During re-assembly, engage the drum sprocket with the wheel along with the drive chain and then 1. Remove the wheel hugger rear. assemble the wheel into swing arm. 2. Remove the axle nut (1) and along with the 7.
  • Page 88 MAINTENANCE STORAGE PROCEDURES 6. Place a suitable support at the bottom of the frame so that both the tyres are off the ground. This will For storage of your motorcycle for longer periods of ensure better tyre life. over a month and above, we recommend to carry out the following steps: 7.
  • Page 89 2. Recommended spark plug one number. required. 3. Turn signal lamp bulb one number. 3. Fill the engine cum transmission oil (TVS TRU4 4. Throttle and clutch cables one number each. FULLY SYNTHETIC - SAE 10W30 API-SL, JASO MA2) and check the oil level using the gauge.
  • Page 90 14. Lubrication of all items mentioned in the periodic maintenance schedule. 15. Intactness of EVAP system hoses and canister. 16. Any other job as necessary. 17. Have your vehicle checked at any TVS Motor Company Authorised Distributor or Dealers / Authorised Service Centers.
  • Page 91: Service Record Sheet

    SERVICE RECORD SHEET SERVICE RECORD S.No. Description Odometer Job card no. / Date Servicing Dealer’s reading stamp and sign. 1st service between (a) 500 - 750 km or (b) 1 month from the date of purchase, whichever of the two occurs earlier. 2nd service between (a) 2500 - 3000 km or (b) 3 months from the date of purchase,...
  • Page 92 SERVICE RECORD SHEET SERVICE RECORD S.No. Description Odometer Job card no. / Date Servicing Dealer’s reading stamp and sign. 5th service between (a) 11500 - 12000 km or (b) 12 months from the date of purchase, whichever of the two occurs earlier. 6th service between (a) 14500 - 15000 km or (b) 15 months from the date of purchase,...
  • Page 93 SERVICE RECORD SHEET SERVICE RECORD S.No. Description Odometer Job card no. / Date Servicing Dealer’s reading stamp and sign. 9th service between (a) 23500 - 24000 km or (b) 24 months from the date of purchase, whichever of the two occurs earlier. 10th service between (a) 26500 - 27000 km or (b) 27 months from the date of purchase,...
  • Page 94: Technical Specifications

    TECHNICAL SPECIFICATION MANUFACTURER : TVS MOTOR COMPANY LIMITED P.B. No1, Bythahalli, Kadakola post, Mysore - 571 311, India. ENGINE ENGINE Type : 4 stroke, Oil cooled, single Engine idling rpm* in cylinder OHC, EFI Sport mode : 1650 ± 200 rpm...
  • Page 95 TECHNICAL SPECIFICATION CHASSIS TYRE* Tyre size Overall length : 2020 mm (without mud flap) Front 90/90 - 17 49P Tubeless : 2050 mm (with mud flap) Overall width : 790 mm Rear 130/70 R17 M/C 62P Tubeless Overall height : 1050 mm (Radial tyre) Seat height : 800 mm...
  • Page 96 Front fork oil capacity : 329 ± 2 ml / leg Turn signal lamp : 12V,10W x 4 Brake fluid : TVS Girling DOT 3 / DOT 4 Number plate lamp : 12V, 5W x 1 Instrument panel : LCD / LED indicators...
