Access to the Ewon Cosy+
eCatcher offers the possibility to create a commissioning file which includes all the configuration
parameters useful to configure such connections.
eCatcher stores the commissioning file on an SD card or a USB flash drive. You can then insert
the SD card or USB flash drive in your Ewon Cosy+ which automatically applies the configuration
parameters available on the SD card / USB flash drive.
If you decide to use a USB flash drive combined with a Ewon Flexy, you need the Flexy USB extension
card: FLB 3601.
Once eCatcher displays the "Talk2M Connectivity" frame, apply the following procedure:
1. Insert an SD card or USB flash drive in your computer. Make sure the card or the key is of
FAT32 format.
2. Click the Launch Setup Wizard button of the USB / SD Card first row.
3. Select the WAN interface of your Ewon Cosy+.
4. Depending on the interface you choose, different configuration fields are required:
– Ethernet: WAN IP settings.
– Wi-Fi: SSID settings.
– Cellular: SIM card and APN settings.
For Ethernet and Wi-Fi, make sure to complete the advanced settings if necessary.
5. Click Next.
6. Set the LAN IP address of your Ewon Cosy+.
7. Click Next.
8. Select the location where eCatcher should export the file.
9. Click Save twice to confirm the export.
The last screen is an explanation how to proceed with the SD card / USB flash drive and your
Ewon Cosy+. You can also follow
3.3

Step 3: Apply the Configuration File

To configure your Ewon Cosy+ for remote access, apply the following procedure:
Ewon Cosy+ User Manual
To apply the following configuration, your Ewon Cosy+ must run (minimum) Ewon Cosy+
firmware version 13.2s0 for the USB drive and 11.0s0 for the SD card.
Step 3: Apply the Configuration File, p.
The following configuration works only if your Ewon Cosy+ hasn't been registered on
Talk2M (or is not currently linked to a Talk2M account).
8 (32)
