Duplo DocuCutter DPC-400 Operation Manual page 18

Test Motions
Knife Action
Knife1 Action
Wheel Action
Sucker Action
Pump ON/OFF
SETUP SCREEN
Head Motion
Knife Depth: Adjusts the knife depth.
UP Arrow The higher the number the lower the
unit goes.
Knife1 Depth: Adjusts the Knife1
DOWN Arrow depth. The higher the number the
lower the unit goes.
Wheel Depth: Adjusts the Wheel
LEFT Arrow depth. The higher the number the
lower the unit goes.
RIGHT Arrow Test Speed: Speed of the Head Unit
Origin
Depth
TOOLS TAB
18
Origin
Back Origin: Head
Unit goes Feeder
postion
Front Origin: Head
unit goes to Home
postion.
Temp Origin: Sets
temporary home
postion.
Manual Feed: feeds
one sheet
