MVI69-GEC ♦ CompactLogix or MicroLogix Platform
Parameter
OP
Run
BlkErrs.Read
BlkErrs.Write
BlkErrs.Parse
BlkErrs.Err
Client[0].Connected
Client[0].State
Client[0].IP
Client[0].Port
Client[0].RxCount
Client[0].RxOverflow
Client[0].TxCount
Client[0].TxOverflow
Client[0].spare
Client[1].Connected
Client[1].State
Client[1].IP
Client[1].Port
Client[1].RxCount
Client[1].RxOverflow
Client[1].TxCount
Client[1].TxOverflow
Client[1].spare
ProSoft Technology, Inc.
February 18, 2014
Block Description
Offset
Start
7 Operating system level as ASCII string
9 Run number as ASCII string
11 Number of blocks transferred from module to processor
12 Number of blocks transferred from processor to module
13 Number of blocks parsed by module
14 Number of block errors in module
15 This flag defines if the client is utilized and connected to a
server. A value of 0 indicates the client is not connected and
can be utilized for a connection. Any other value indicates
the client is connected and being used.
16 This flag defines the current state of the client.
17 This double-word value contains the IP address of the server
connected to the client.
19 This word value contains the port address for the server
connected to the client.
20 This status value contains the total number of messages
received by the client.
21 This status value contains the total number of messages
received that exceed the specified buffer size for the client.
22 This status value contains the total number of messages
transmitted by the client.
23 This status value contains the total number of transmit
messages that exceeded the specified maximum buffer size
for the client.
24 Reserved for future use
25 This flag defines if the client is utilized and connected to a
server. A value of 0 indicates the client is not connected and
can be utilized for a connection. Any other value indicates
the client is connected and being used.
26 This flag defines the current state of the client.
27 This double-word value contains the IP address of the server
connected to the client.
29 This word value contains the port address for the server
connected to the client.
30 This status value contains the total number of messages
received by the client.
31 This status value contains the total number of messages
received that exceed the specified buffer size for the client.
32 This status value contains the total number of messages
transmitted by the client.
33 This status value contains the total number of transmit
messages that exceeded the specified maximum buffer size
for the client.
34 Reserved for future use
