Printing a Configuration File
1 In the main PCB window, right-click the M
2 In the View Configuration dialog box, open the F
3 In the Print dialog box, choose the printer to use from the drop-down list, select the
printing options, and then click OK.
2.2 [Module]
This section of the file describes the database setup and module level parameters.
[Module]
Module Name: MVI69-GEC Communication Module DEFAULT
0 to 80 characters
Specifies a name to identify the module and the configuration file.
2.3 [Server x]
You can configure up to five servers ([Server 0] through [Server 4]). The configuration
section for each server contains the same set of parameters. You can configure the
parameters for each server to meet the requirements of your application.
2.3.1 Enabled
Yes or No
This parameter determines if the server will be utilized by the module. If a value of "Yes" is
entered, the server will be used. Any other value will disable the server.
2.3.2 Service Port Number
1 to 65535
This parameter sets the TCP/IP service port for this server. Each server can have its own
unique service port or can share the same number with other servers.
2.3.3 Connection Timeout
0 or 5000 to 65535
This parameter specifies the number of milliseconds the server will permit the server to be
inactive after a connection is made before closing the socket. This timeout period is reset on
each read or write packet. If the parameter is set to 0, the connection will not timeout.
