MVI69-GEC ♦ CompactLogix or MicroLogix Platform
2 On the shortcut menu, select C
Module Type dialog box.
3 In the Product Line Filter area of the dialog box, select MVI69. In the Select Module Type
dropdown list, select MVI69-GEC, and then click OK to save your settings and return to
the ProSoft Configuration Builder window.
2.1.2 Renaming PCB Objects
You can rename objects such as the Default Project and Default Location folders in the tree
view. You can also rename the Module icon to customize the project.
1 Right-click the object you want to rename and choose R
2 Type the new name for the object and press Enter.
Configuring Module Parameters
1 Click the [+] sign next to the module icon to expand module information.
ProSoft Technology, Inc.
February 18, 2014
M T . This action opens the Choose
HOOSE ODULE YPE
.
ENAME
