3.3.4
Recording Presets
The presets will provide a quick setup for some basic recording
configurations. The audio quality will be high in all cases. After
selecting a preset, the individual settings can be changed to your
needs. The following presets can be selected:
Preset Built-in Microphone: This is the default setting, recording
from the built-in microphone.
Preset 3.5mm Microphone: Records the audio from a microphone
that is plugged into the 3.5mm MIC2 jack.
Preset Phantom Microphone: Records the audio from a microphone
that is plugged into the 6.35mm MIC1 jack. Phantom power is also
switched on!
Preset Aviation Headset: Special setting for a headset, used by
aviation pilots.
Recording File Format
The Recording File Format sets the compression type, the sample rate
and the number of channels in the WAV files on SD. This determines
the quality of the recording for playback later on and also the
remaining recording time for storage on the SD card.
The following formats are available:
U-Law 8 bit, 8kHz, Mono
A-Law 8 bit, 8kHz, Mono
U-Law 8 bit, 16kHz, Mono
A-Law 8 bit, 16kHz, Mono
U-Law 8 bit, 8kHz, Stereo
A-Law 8 bit, 8kHz, Stereo
U-Law 8 bit, 16kHz, Stereo
A-Law 8 bit, 16kHz, Stereo
PCM 16 bit , 16kHz, Mono
PCM 16 bit , 16kHz, Stereo
PCM 16 bit , 48kHz, Mono
PCM 16 bit , 48kHz, Stereo
V-Mic Manual EN v1.5 Juli 2020

Recording Settings

Storage Rate
8k bytes/sec
8k bytes/sec
16k bytes/sec
16k bytes/sec
16k bytes/sec
16k bytes/sec
32k bytes/sec
32k bytes/sec
32k bytes/sec
64k bytes/sec
96k bytes/sec
192k bytes/sec
