Summary of Contents for Light Sky MINI LASER AQUA
- Page 1 MINI LASER AQUA Please read the instruction carefully bef!
-
Page 2: Table Of Contents
CONTENTS ....................2 1. Safety Instructions ...................5 2. Technical Specifications ..................7 2.1. Attachment And Size .....................9 3. Color/Gobo/Prism ..................10 4. Connection and control ................10 4.1. Power supply connection ..................11 4.2. DMX 512 Connection ....................12 4.3. Control Panel ....................13 5. How To Set The Unit ....................13 5.1. -
Page 3: Safety Instructions
1.Safety Instructions Please read the instruction carefully which includes important information about the installation, usage and maintenance. WARNING Please keep this User Manual for future consultation. If you sell the unit to another user, be sure that they also receive this manual. The following symbols are used to identify important safety information on the product and in this manual: Laser radiation... - Page 4 The unit must be installed in a location with adequate ventilation, at least 20cm from adjacent surfaces. Be sure that no ventilation slots is blocked, otherwise the unit will be overheated. Before operation, ensure that you are connecting this product to the proper voltage in accordance with the specifications in this manual or on the product’s specification label.
- Page 5 Do not operate this product if you see damage on the housing, shields, or cables. Have the damaged parts replaced by an authorized technician at once. Class 1 laser products (IEC 60825-1:2014) - RG3 (IEC 62471:2006). Warn! Do not look directly at the light source at work, as it may damage the retina of the eye and cause visual blindness.
-
Page 6: Technical Specifications
2.Technical Specifications OPTICS - Light source: white laser - Laser source life expectancy: 12000 hours *Laser source life depends on several factors, including but not limited to:environmental conditions, control dimming, power supply and voltage, switchingcycle, fixture mode, etc. - Beam angle: 1.1° - Optical lens: φ128mm HD lens - Whole lamp output illumination: 350000lux@10 meters COLOR... - Page 7 SIZE &WEIGHT - Product size: 329×222×508mm - Carton packaging (default): 410×290×625mm - N.W.: 13.7kg G.W.: 17.3kg ：850 660 725 Flycase Size( sets) - N.W.: 54.8 kg G.W.: 106.0 kg OTHER - Protection level: IP66 - Working environment: -20℃ ~ 45℃ - Maximum temperature of lamp body surface: 80℃...
-
Page 8: Attachment And Size
2.1.Attachment And Size Attachment contents-Fig.1 power cord Certificate of conformity Size-Fig.2 (Unit:mm) -
Page 10: Color/Gobo/Prism
3.Color/Gobo/Prism Color disk+CMY CTO2 UV blue Lavender Static gobo wheel White Prism 8 Prism 24 Prism... -
Page 11: Connection And Control
4.Connection and control 4.1.Power supply connection POWER POWER END The ground wire is connected to the yellow-green wire The N terminal is connected with the blue line. The L terminal is connected with the brown line. Watertight seal ring Watertight seal ring - The bus connecting the power supply must be installed by a qualified professional technician. -
Page 12: Dmx 512 Connection
4.2.DMX 512 Connection DMX512 in SIGNAL END DMX-input DMX - output - Shield 1 - Shield - Signal (-) 2 - Signal (-) - Signal (+) - Signal (+) - Not connected - Not connected - Not connected - Not connected 1. -
Page 13: Control Panel
4.3.Control Panel 1.Display: To show the various menus and the selected function. 2.Button： OK confirmation key DOWN To the left To the right -12-... -
Page 14: How To Set The Unit
5.How To Set The Unit 5.1.Main Function The lamp is powered on. When the system initialization and lamp reset are completed, and the standby interface is displayed on the display screen, press OK to enter the preset menu interface. The main functions are as follows: Main menu I menu II menu... -
Page 15: Address Setting
5. 2. Address Setting 6.3 Address Setting Enter MENU, select the DMX setting function, select the address code setting, press the OK button to confirm, the current DMX address will be displayed on the display. Use the up/down buttons to select addresses 001~512, and press the OK button to save. -
Page 16: Dmx 512 Configuration
5.3.DMX 512 Configuration Please control the fixture by referring to the configurations below 17 Channel 19 Channel Function Note 0--255 Pan positioning 0--255 Fine Pan positioning 0--255 Tilt positioning 0--255 Fine Tilt positioning 0--255 Speed pan/tilt DeviceSet(Hold 3s） 0-25 No function 26-30 Reset Head 31-35... - Page 17 17 Channel 19 Channel Function Note 176-185 Color9 186-195 Color9 + Color10 196-205 Color10 206-215 Color10 + Color11 216-225 Color11 226-235 Color11 + Color12 236-245 Color12 246-255 Color wheel shake slow to fast FixgoboWheel Open 9-11 FixGobo 1 12-14 FixGobo 2 15-17 FixGobo 3 18-20...
-
Page 18: Electrical Connection Diagram
6.Electrical Connection Diagram -17-... -
Page 19: Troubleshooting
7.Troubleshooting The following are common faults of lamps and corresponding solutions. Faults that cannot be repaired by yourself should be handled by professionally qualified personnel. Disconnect the power supply to the lamp during maintenance! ● The light source is not bright - Check that a suitable light source is installed for the luminaire. - Page 20 - Check whether the power supply is insufficient, and whether the power switch and wiring are in poor contact or aging. - Check whether the over-temperature protection temperature switch inside the lamp is damaged. ● Although it emits light, the lamp does not accept instructions from the controller - Check whether the digital start address value and function options of the lamp are correct.
-
Page 21: Fixture Cleaning
8.Fixture Cleaning It is absolutely essential that the fixture is kept clean to ensure the maximum light-output and allow the fixture to function reliably throughout its life. The fixture must be cleaned regularly to avoid dust, dirt and smoke-fluid residues building up on or within the fixture. The cleaning frequency depends on the application environment.
