IPL EXP I/O Series • Setup Guide (Continued)
Control, Bidirectional — LAN/PoE (Ethernet)
Insert
Twisted Pair Wires
RJ-45
Connector
Pins:
8 7 6 5 4 3 2 1
Rear
Panel
IPL EXP 200
or
Activity
LAN/PoE
LED
ATTENTION:
•
Power over Ethernet (PoE) is intended for indoor use only. It is to be connected only to networks or circuits that are not
routed to the outside plant or building.
•
L'alimentation via Ethernet (PoE) est destinée à une utilisation en intérieur uniquement. Elle doit être connectée
seulement à des réseaux ou des circuits qui ne sont pas routés au réseau ou au bâtiment extérieur.
MAC address: Each IPL EXP expansion interface is assigned a unique user hardware ID number
(MAC address) (for example, 00-05-A6-05-1C-A0). You may need this address during configuration.
A label that indicates the MAC address is located on the rear of the unit.
Control, Unidirectional — IR/Serial
To a Projector,
Panel Display, or the
IR or RS-232
Wired IR Remote or
RS-232 Port of a
Source Device
8
TCP/IP
Network
Ethernet
Default protocol, public ports:
• IPL EXP IP address: 192.168.254.250
• Gateway IP address: 0.0.0.0
• Subnet mask: 255.255.255.0
• DNS address: 127.0.0.1
• DHCP client: off
• Link speed and duplex level: autodetected
IPL EXP RIO8
• Data rates: 10/100Base-T
Link
LED
PoE or PoE+
• Connect to a network that
provides PoE+
(IPL EXP RIO8) or PoE or
LAN / PoE+
PoE+ (all other models) or to
an active power injector.
• Front panel LED (
during boot-up and remains
lit when the unit is powered
and operational.
IPL EXP 200
RearPanel
1 2 3 4
Tx Rx G Tx Rx G
S G S G S G S G
COM 1 COM M 1 1
COM 2 COM 2 2 2 R E R R R R RELAYS E E L L AYS
IR/S
Tx Rx G Tx Rx G 5 S G 6 7 1 2 C 1 2 C 8
S G S G S G S G
IR/SERIAL
or
Output
Ground
Unidirectional
IR
NOTE:
PC
LAN (Ethernet)
) blinks
IR/Serial Ports
Output options:
• IR (30 kHz to 300 kHz,
with or without carrier signals)
• Unidirectional RS-232
(-)
(+)
(-)
(-)
G Ground
S IR Output Signal
(+) (+)
Two Single IR Emitters
The factory configured password
for this device has been set to the device
serial number. Passwords are case sensitive.
Performing a Reset to Factory Defaults reset
(see Reset Modes: a Brief Summary
page 12) sets the password to extron.
Default login
credentials:
• Username:
admin or
Front Panel,
user
IPL EXP RIO8
• Password:
extron
IPL EXP RIO8
Front Panel,
100
IPL EXP RIO8
LINK
ACT
R
00-05-A6-XX-XX-XX
MAC: 00-05-A6-XX-XX-XX
S/N: ####### E######
MAC: 00-05-A6-XX-XX-XX
S/N: ####### E######
To the IR Receiver of a
Projector, Display, or
Source Device
on
100 Mbps
Connection
Network is
active.
Data is being
sent/received.
MAC
Address
