JFP1, JFP2: Frontpanel-Anschlüsse
Diese Anschlüsse verbinden die Schalter und LEDs des Frontpanels.
Power LED
2
1
HDD LED
JFP2
1
14
Übersicht der Komponenten
Power Switch
10
9
Reserved
Reset Switch
Buzzer
1
Speaker 3
1 HDD LED +
3 HDD LED -
5 Reset Switch
7 Reset Switch
9 Reserved
HDD LED
POWER LED
Speaker -
Buzzer -
2 Power LED +
4 Power LED -
6 Power Switch
8 Power Switch
10 No Pin
HDD LED -
HDD LED +
POWER LED -
POWER LED +
2 Buzzer +
4 Speaker +
