JFP1, JFP2: 系統面板接頭
這些接頭用於連接前面板的開關和 LED 指示燈。
Power LED Power Switch
2
1
HDD LED Reset Switch
JFP2
1
1
3
10
5
9
Reserved
7
9
Buzzer
1
Speaker 3
HDD LED +
HDD LED -
Reset Switch
Reset Switch
Reserved
HDD LED
POWER LED
Speaker - 2
Buzzer - 4
2 Power LED +
4 Power LED -
6 Power Switch
8 Power Switch
10 No Pin
HDD LED -
HDD LED +
POWER LED -
POWER LED +
Buzzer +
Speaker +
元件總覽
13
