Specifications

CPU
Chipset
Memory
Expansion Slots
Onboard
Graphics
∙ Supports 10th Gen Intel® Core™ Processors, 11th Gen Intel®
Core™ Processors, Pentium® Gold and Celeron® Processors
∙ Processor socket LGA1200
* Please go to intel.com for compatibility information.
Intel® H510/ B560 chipset
∙ 2x DDR4 memory slots, support up to 64GB*
∙ Supports 1R 2133/ 2666/ 2933 MHz for 10th Gen Intel® CPU
(by JEDEC & POR)
∙ Supports 1R 2133/ 2666/ 2933/ 3200 MHz for 11th Gen Intel®
CPU (by JEDEC & POR)
∙ Max overclocking frequency (For B560M PRO-E/ B560M
PLUS/ B560M-X):
▪ 1DPC 1R Max speed up to 4800 MHz
▪ 1DPC 2R Max speed up to 4600+ MHz
∙ Supports Dual-Channel mode
∙ Supports non-ECC, un-buffered memory
∙ Supports Intel® Extreme Memory Profile (XMP)
* Please refer to www.msi.com for more information on
compatible memory.
∙ 1x PCIe x16 slot (From CPU)
▪ Support up to PCIe 4.0 for 11th Gen Intel® CPU
▪ Support up to PCIe 3.0 for 10th Gen Intel® CPU
∙ 1x PCIe 3.0 x1 slot (From PCH)
∙ 1x M.2 slot with E key for WiFi module only(M2_2) (For
H510M PRO/ H510M-A PRO/ H510M BOMBER)
∙ 1x HDMI 2.0b with HDR port, supports a maximum
resolution of 4K 60Hz*/**
∙ 1x VGA port, supports a maximum resolution of 2048x1536
60Hz, 1920x1200 60Hz (For H510M PRO/ H510M-A PRO/
H510M BOMBER/ B560M PRO-E/ B560M-X)*
∙ 1x DisplayPort 1.4 port, supports a maximum resolution of
4K 60Hz (For H510M PRO)*/**
* Available only on processors featuring integrated graphics.
** Graphics specifications may vary depending on the CPU
installed.
Continued on next page
3
