Terminal Identification - Altronix Isolated Series Installation Manual

7. Set power switch on all models to the "RESET" (ON) position (Figs. 1-3, pgs. 3-5).
8. Upon completion of the wiring, secure enclosure door with screws (supplied).
CAUTION: Equipment to be installed/serviced by authorized/trained personnel only.
Shut branch circuit power before installing/servicing equipment.
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or moisture. This installation
should be made by qualified service personnel and should conform to all local codes and in accordance with the
National Electrical Code. Use 75
fuses with same type and rating (3.5A/250V).
PD8i - Power Distribution Module
1A - 8A Phase 1.
1B - 8B Phase 2.
Fig. 1
ALTV248ULHi • ALTV248ULCBHi
non power-limited
1A 2A 3A 4A
1B 2B 3B 4B
F1 F2 F3
Green
Lead
(ground)
UL Listed Isolated Series
o
C or higher rated UL insulated wiring for connecting unit to the mains. Replace

Terminal Identification:

5A 6A 7A 8A
5B 6B 7B 8B
F4 F5 F6 F7 F8
Power
5A
Switch
250V
XFMR*
115VAC input
50/60 Hz.
non power-limited
Available from A1 Security Cameras
www.a1securitycameras.com email: sales@a1securitycameras.com
Used on PTC Models
(example: ALTV248ULCBHi)
Class 2 power-limited
1A 2A 3A 4A 5A 6A
1B 2B 3B 4B 5B 6B
F1 F2 F3 F4 F5 F6
WARNING:
Change fuses with the
same type and rating:
Input: 5A @ 250V
Output: 3.5A @ 250V
7A 8A
7B 8B
F7 F8
- 3 ­
