Isolated Series
UL Listed Rack Mount
CCTV Power Supplies
Installation Guide
Models Include:
R248ULi
- 24VAC @ 12.5A (300VA) total output.
- Eight (8) 1.56A Fuse Protected
Isolated Outputs.
R2416ULi
- 24VAC @ 25A (600VA) total output.
- Sixteen (16) 1.56A Fuse Protected
Isolated Outputs.
Rev. 092904
R248ULCBi
- 24VAC @ 12.5A (300VA) total output.
- Eight (8) 1.56A PTC Protected
Isolated Outputs.
R2416ULCBi
- 24VAC @ 25A (600VA) total output.
- Sixteen (16) 1.56A PTC Protected
Isolated Outputs.
More than just power.
TM
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Altronix R248ULi
Summary of Contents for Altronix R248ULi
-
Page 1: Installation Guide
Isolated Series UL Listed Rack Mount CCTV Power Supplies Installation Guide Models Include: R248ULi R248ULCBi - 24VAC @ 12.5A (300VA) total output. - 24VAC @ 12.5A (300VA) total output. - Eight (8) 1.56A Fuse Protected - Eight (8) 1.56A PTC Protected Isolated Outputs. -
Page 2: Specifications
(blown fuse or tripped PTC), the corresponding LED will not be illuminated (Fig. 1, pg. 3). a. Blown fuse (R248ULi & R2416ULi) - Set power switch the on back of the unit to the OFF position (Fig. 1c, pg. 3). Remove front faceplate to access fuses. Replace with fuses rated @ 3.5A/250VA (Altronix model # Fuse1). - Page 3 9. Power switch with built-in circuit breaker: OFF position - Switch not illuminated. Outputs not powered. RESET (ON) position - Switch illuminated. Outputs powered. Circuit breaker tripped - Switch not illuminated. Power LEDs on faceplate are not illuminated. Outputs not powered. To reset circuit breaker set power switch to the ON (RESET) position (Fig. 1c, pg. 3). Note: Do not exceed units electrical load ratings as indicated in reference chart (pg.
-
Page 4: Rear View
Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IIR248/2416 UL Listed Isolated Rack Mount Series...
