Isolated Series
Rack Mount CCTV Power Supplies
Installation Guide
Models Include:
R248I220
- 24VAC @ 12.5A (300VA) total output.
- Eight (8) 1.75A Fuse Protected
Isolated Outputs.
R2416I220
- 24VAC @ 25A (600VA) total output.
- Sixteen (16) 1.75A Fuse Protected
Isolated Outputs.
Rev. 120604
R248CBI220
- 24VAC @ 12.5A (300VA) total output.
- Eight (8) 1.75A PTC Protected
Isolated Outputs.
R2416CBI220
- 24VAC @ 25A (600VA) total output.
- Sixteen (16) 1.75A PTC Protected
Isolated Outputs.
More than just power.
TM
Advertisement
Related Manuals for Altronix Isolated Series
Summary of Contents for Altronix Isolated Series
- Page 1 Isolated Series Rack Mount CCTV Power Supplies Installation Guide Models Include: R248I220 R248CBI220 - 24VAC @ 12.5A (300VA) total output. - 24VAC @ 12.5A (300VA) total output. - Eight (8) 1.75A Fuse Protected - Eight (8) 1.75A PTC Protected Isolated Outputs.
- Page 2 Overview: Altronix Isolated Series Rack Mount CCTV Power Supplies provide 24VAC distributed via mutltiple fuse or PTC protected isolated outputs for powering CCTV cameras, heaters, and other video accessories. Isolated Rack Mount Configuration Reference Chart: Protected Output 220VAC Total Output...
- Page 3 Note: Do not exceed units electrical load ratings as indicated in reference chart (pg. 2). Do not place mechanical load on unit. Data racks should always be properly ventilated. Unit is designed optimally for normal data room office installations. CAUTION: Equipment to be installed / serviced by authorized / trained personnel only.
- Page 4 Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER II Isolated Rack Mount 220 Series...
